TAOXING Высокоточный Серводвигатель Автоматическая цилиндрическая трафаретная печатная машина для
- Категории: Screen Printers >>>
- Поставщик: Hangzhou,Taoxing,Printing,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Specifications
Application:
Our cylindrical screen printing machine are also known as circular or cylindrical screen printing machine. Which are well designed for round, oval, square and other special shape containers curved surface printing, available to print on plastic, glass and metal bottles. The cylindrical screen printing machines are widely used for industries of daily chemical, food, beverage, pharmaceutical, chemical, personalized water bottles business, cosmetic bottles manufacture, etc. Advanced servo motors and optical color sensor are used for color registration with accuracy.
Features:
1. PLC programming, touching screen, simple to operate, easy to use
2. Built in digital counts for production output
3. Facilitate to placement of the product benefit from special design famous air cylinders
4. Servo motor drive rotating and printing head ensure high precision
5. Self-balance scraper technology and ink cover blade
6. Printing Stroke and rotation by digital adjustments, printing speed controllable.
7. Convenient operating the height of the printing beam by hand wheel.
8. Easy to disassemble and cleaning the screen plate due to the independent design of lifting printing head including scraper and squeegee;
9. Quality photoelectricity sensor and perfect fault self-detect system.
10.Metal structure，running steady, foot switch for starter.
2. Built in digital counts for production output
3. Facilitate to placement of the product benefit from special design famous air cylinders
4. Servo motor drive rotating and printing head ensure high precision
5. Self-balance scraper technology and ink cover blade
6. Printing Stroke and rotation by digital adjustments, printing speed controllable.
7. Convenient operating the height of the printing beam by hand wheel.
8. Easy to disassemble and cleaning the screen plate due to the independent design of lifting printing head including scraper and squeegee;
9. Quality photoelectricity sensor and perfect fault self-detect system.
10.Metal structure，running steady, foot switch for starter.
Parameters:
Model | TX-500SS |
Max printing size | 500*200mm |
Max frame size | 700x350mm |
Max product length | ≤300mm |
Product Diameter | ≤160mm |
Max printing speed | 800（PCS/H） |
Air pressure | 5bar |
Voltage/Power | 220V,50/60HZ,500W |
Dimension | 104*99*170cm |
Weight | 150kg |
Gross Weight | 272kg |
Machine Description
Recommend Products
Buyer Comment
Company Profile
Certification
Packing&Delivery
FAQ
Q: Are you a factory or trading company?
A: We are a professional manufacturing factory specialize in printing equipment with more than 20 years experience, committed to supplying our customer top quality and dedication to the constant improvements of quality,reliability, productivity and the competitiveness of our products and services.
Q: How to get a quotation?
A: Please send us an inquiry directly. We need to get specific details, such as material, size, color,thickness, quantity, etc.
Q: Can you do the production as customized?
A: Yes, we have a professional technique team, we could produce the machine depends on
your requirements.
Q: What are your terms of payment?
A: We accept TT/LC/PAYPAL/Western union, every payment term we can discuss.
Q: How long is the warranty time?
A: All products carry up to a full year warranty. Supply wearing parts with favorable price and long term after-sales service. We believe in total customer satisfaction, aside from our no-hassle guarantee.
Q: How to get a quotation?
A: Please send us an inquiry directly. We need to get specific details, such as material, size, color,thickness, quantity, etc.
Q: Can you do the production as customized?
A: Yes, we have a professional technique team, we could produce the machine depends on
your requirements.
Q: What are your terms of payment?
A: We accept TT/LC/PAYPAL/Western union, every payment term we can discuss.
Q: How long is the warranty time?
A: All products carry up to a full year warranty. Supply wearing parts with favorable price and long term after-sales service. We believe in total customer satisfaction, aside from our no-hassle guarantee.
