Топовый бренд! Liugong бренд 14 тонн дорожный каток с Одним Барабаном
- Категории: >>>
- Поставщик: Shandong,Ocean,Import,&,Export,Co.,Ltd.Shandong,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Operating Mass | 14000 kg |
Mass On Front Drum | 7000 kg |
Mass On Rear Axle | 7000 kg |
Front Drum Static Linear Load | 329 N/cm |
Rear Drum Static Linear Load | 329 N/cm |
Model | Cum-mins QSB4.5 |
Emission Regulation | Stage III |
Rated Power | 119 kW (162 hp) @ 2200 rpm |
Vibration Frequency Low | 45/50 Hz |
Nominal Amplitude Low | 0.75/0.4 mm |
Centrifugal Force Low | 166/99 kN |
Vibration Frequency High | 50/67 Hz |
Nominal Amplitude High | 0.8/0.3 mm |
Centrifugal Force High | 185/115 kN |
Drum Diameter | 1350 mm |
Drum Width | 2130 mm |
1st Maximum Speed, fwd | 0-6 km/h |
2nd Maximum Speed, fwd | 0-8 km/h |
3rd Maximum Speed, fwd | 0-12 km/h |
Theoretical Gradeability | 40% |
Min. Ground Clearance | 345 mm |
Wheelbase | 3585 mm |
Min. Outside Turning Radius | 6770 mm |
Overall Length | 5050 mm |
Overall Width | 2300 mm |
Overall Height | 3195 mm |
Specifications :
* Flexible and non-impact technology on our vibratory rollers extends the vibratory bearing’s working life to beyond 10,000 hours
increasing productivity and reducing part wear.
* With a larger diameter drum, combined with amplitude consistency and uniformity, we ensure that the optimum compaction force is
delivered with fewer passes required.
* Patented cooling technology inside the drum keeps temperatures balanced at around 90° centigrade, 20° lower than the industry
average. This stable temperature regulation helps prolong component life and reduces maintenance
increasing productivity and reducing part wear.
* With a larger diameter drum, combined with amplitude consistency and uniformity, we ensure that the optimum compaction force is
delivered with fewer passes required.
* Patented cooling technology inside the drum keeps temperatures balanced at around 90° centigrade, 20° lower than the industry
average. This stable temperature regulation helps prolong component life and reduces maintenance
The unique Liugong non-impact vibration exciter, flexible start and stop vibration, avoid the impact of the shaker exciter from start
and stop vibration, eliminate the risk of eccentric block fracture, effectively extend the service life of the vibrating bearing
and eccentric shaft, and ensure the high reliability of the vibration system;
The unique Liugong damping control technology realizes "soft acceleration and soft deceleration", avoids the start and stop of the
asphalt pavement, and ensures the ultra-high flatness of the compacted pavement;
The vibration frequency is higher, the amplitude is lower, and the excitation force is greater, which can easily achieve the
flatness and compaction required by the expressway;
Equipped with imported brand hydraulic system, stable and reliable, long service life;
Intelligently control the engine power output according to the working conditions, and the overall fuel saving of the whole
machine can reach more than 8%;
Crab line design, convenient edge pressing, intermittent watering, easy control;
The front and back vision is wide, satisfying the one-meter-by-meter vision.
and stop vibration, eliminate the risk of eccentric block fracture, effectively extend the service life of the vibrating bearing
and eccentric shaft, and ensure the high reliability of the vibration system;
The unique Liugong damping control technology realizes "soft acceleration and soft deceleration", avoids the start and stop of the
asphalt pavement, and ensures the ultra-high flatness of the compacted pavement;
The vibration frequency is higher, the amplitude is lower, and the excitation force is greater, which can easily achieve the
flatness and compaction required by the expressway;
Equipped with imported brand hydraulic system, stable and reliable, long service life;
Intelligently control the engine power output according to the working conditions, and the overall fuel saving of the whole
machine can reach more than 8%;
Crab line design, convenient edge pressing, intermittent watering, easy control;
The front and back vision is wide, satisfying the one-meter-by-meter vision.
1:Which countries do you export to?
Asia: India, Philippines, Thailand, Burma, Vietnam, Bangladesh, Kazakhstan, Turkmenistan, etc. Middle East: Saudi Arabia, UAE, Jordan, Oman, Pakistan, Qatar, etc. Europe: Russia, Ukraine, Belarus, Bulgaria, etc. Africa: South Africa, Kenya, Congo, Ethiopia, Nigeria, Ghana, Algeria, Senegal, Tunisia, etc. South America: Brazil, Peru, Chile, Mexico, etc. Oceania: Papua New Guinea, Australia, etc.
2 :What is the proportion of your products exported?
75% of our products are exported to all over the world.
3 :What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers. TT, L/C, D/P, depending on the cooperation time, country and contract value.
4 :What kind of logistic service do you supply?
a. Transportation: railway transportation, international through transport, including (international railway through transportation, Sea-rail intermodal through transportation, sea-land multimodal transportation. Means of transport: Container, LCL, FRC, ro-ro, bulk cargo, train carriage , truck, air plane.
b. Term: FOB, CIF, DAP, to door service, etc.
5 :What spare parts can you supply?
All kinds of spare parts of XCM G, SHANTUI, ZOOMLION, SINOTRUCK, SHACMAN, LIUGONG, SDL G, LONKING, XGMA, CUMMINS ENGINE, ZF GEAR BOX, etc.
Asia: India, Philippines, Thailand, Burma, Vietnam, Bangladesh, Kazakhstan, Turkmenistan, etc. Middle East: Saudi Arabia, UAE, Jordan, Oman, Pakistan, Qatar, etc. Europe: Russia, Ukraine, Belarus, Bulgaria, etc. Africa: South Africa, Kenya, Congo, Ethiopia, Nigeria, Ghana, Algeria, Senegal, Tunisia, etc. South America: Brazil, Peru, Chile, Mexico, etc. Oceania: Papua New Guinea, Australia, etc.
2 :What is the proportion of your products exported?
75% of our products are exported to all over the world.
3 :What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers. TT, L/C, D/P, depending on the cooperation time, country and contract value.
4 :What kind of logistic service do you supply?
a. Transportation: railway transportation, international through transport, including (international railway through transportation, Sea-rail intermodal through transportation, sea-land multimodal transportation. Means of transport: Container, LCL, FRC, ro-ro, bulk cargo, train carriage , truck, air plane.
b. Term: FOB, CIF, DAP, to door service, etc.
5 :What spare parts can you supply?
All kinds of spare parts of XCM G, SHANTUI, ZOOMLION, SINOTRUCK, SHACMAN, LIUGONG, SDL G, LONKING, XGMA, CUMMINS ENGINE, ZF GEAR BOX, etc.
