Cheap Professional Industrial 2800r/min DSZG-12 CNC Drilling Tapping Machine for machining
- Категории: Drilling Machines >>>
- Поставщик: Cixi,Dingke,Machinery,&,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Specification
item | value |
Condition | New |
type | Column Drilling Machine |
Max. Drilling Dia. (mm) | 12mm |
Range of Spindle Speed(r.p.m) | 1r.p.m - 2800r.p.m |
CNC or Not | CNC |
Place of Origin | China |
Zhejiang | |
Brand Name | CDK |
Model Number | DSZG-12 |
Dimension(L*W*H) | 630*770*950mm |
Weight (KG) | 125KG |
Warranty | 1 Year |
Key Selling Points | Automatic |
Showroom Location | None |
Applicable Industries | Garment Shops, Building Material Shops, Manufacturing Plant, Construction works |
Marketing Type | New Product 2021 |
Machinery Test Report | Provided |
Video outgoing-inspection | Provided |
Warranty of core components | 2 years |
Core Components | Motor |
Name | Drilling Tapping Machine |
CNC yes or not | Yes |
Product name | CNC Drilling Tapping Machine |
Tapping Capacity | M10 |
Drilling Capacity | 10mm |
Spindle travel | 100mm |
Taper | MT.2 |
Column diameter | 85mm |
Main spindle to working table | 480mm |
Main Characteristics
1. Designed according to CNC machining center.
2. This machine adopts double servo motor feed, one used to spindle rotation,the other to spindle feed power,
3. Using the drilling and tapping combination drill, thethreaded through hole can be processed at one time and the synchronization is strong.
4. Simple operation, repeatability up to 0.02mm.
2. This machine adopts double servo motor feed, one used to spindle rotation,the other to spindle feed power,
3. Using the drilling and tapping combination drill, thethreaded through hole can be processed at one time and the synchronization is strong.
4. Simple operation, repeatability up to 0.02mm.
Related Products
Packing & Delivery
Each drilling and tapping machine is wrapped with stretch film or packed in a wooden case.
Company Profile
DingKe Machinery & Equipment Co.,Ltd. was established in 1996, the company manufacturing base is located in Ningbo City, Zhejiang Province,Is a professional engaged in CDK brand design and manufacture of precision automatic drilling machine, precision automatic tapping machine, precision multi axis drilling / tapping teeth, high precision power main shaft and nut tapping machine, all kinds of automatic drilling / attack teeth of various special machine and automatic assembly machine and other products R & D, design, production, manufacture and sales service in one of the well-known brand enterprises.
The company has the domestic first-class R & D and survival of technical personnel and management team, production and processing equipment and advanced testing equipment complete reliability.
Since 2008, in order to improve the company's management level and strengthen the protection of product knowledge, application and through the ISO9001 quality system certification and CE safety certification, apply "CDK" logo is a registered trademark of the company, and also apply for a dozen of utility model and appearance of the patent protection and number therein, English company domain name in order to improve the company's image and marketing category.
To better meet customer demand in supporting, operating at the same time, Japan YAMWA, OSG, YG brand silk attack, drills, die, CNC cutting tools, such as and well-known brands in Taiwan special drilling, tapping teeth, NC machining precision collet chuck, chuck and other series products. At the same time, according to customer demand for customized non-standard tools and ancillary equipment, welcome to inquire!
The company has the domestic first-class R & D and survival of technical personnel and management team, production and processing equipment and advanced testing equipment complete reliability.
Since 2008, in order to improve the company's management level and strengthen the protection of product knowledge, application and through the ISO9001 quality system certification and CE safety certification, apply "CDK" logo is a registered trademark of the company, and also apply for a dozen of utility model and appearance of the patent protection and number therein, English company domain name in order to improve the company's image and marketing category.
To better meet customer demand in supporting, operating at the same time, Japan YAMWA, OSG, YG brand silk attack, drills, die, CNC cutting tools, such as and well-known brands in Taiwan special drilling, tapping teeth, NC machining precision collet chuck, chuck and other series products. At the same time, according to customer demand for customized non-standard tools and ancillary equipment, welcome to inquire!
FAQ
1. who are we?
We are based in Zhejiang, China, start from 2011,sell to Domestic Market(60.00%),North America(12.00%),Eastern Europe(10.00%),Southeast Asia(5.00%),South Asia(5.00%),South America(3.00%),Oceania(00.00%),Eastern Asia(00.00%),Western Europe(00.00%),Central America(00.00%),Southern Europe(00.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Mechanical Equipment
4. why should you buy from us not from other suppliers?
1) More than 20 years experience on multi-spindle drilling and tapping machine manufacturing;
2) Professional technology and sales team for customized solution and ensure high quality;
3) Our main market is South-East Asia;
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU；
Accepted Payment Currency:USD,EUR,CAD;
Accepted Payment Type: T/T,L/C,Western Union,Cash;
Language Spoken:English,Chinese,Japanese
We are based in Zhejiang, China, start from 2011,sell to Domestic Market(60.00%),North America(12.00%),Eastern Europe(10.00%),Southeast Asia(5.00%),South Asia(5.00%),South America(3.00%),Oceania(00.00%),Eastern Asia(00.00%),Western Europe(00.00%),Central America(00.00%),Southern Europe(00.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Mechanical Equipment
4. why should you buy from us not from other suppliers?
1) More than 20 years experience on multi-spindle drilling and tapping machine manufacturing;
2) Professional technology and sales team for customized solution and ensure high quality;
3) Our main market is South-East Asia;
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU；
Accepted Payment Currency:USD,EUR,CAD;
Accepted Payment Type: T/T,L/C,Western Union,Cash;
Language Spoken:English,Chinese,Japanese
