Новая Клеммная колодка в японском стиле SiRON T044 40-контактный разъем Высококачественная универсальная PLC разрывная
Новая Клеммная колодка в японском стиле SiRON T044 40-контактный разъем Высококачественная универсальная PLC разрывная
Новая Клеммная колодка в японском стиле SiRON T044 40-контактный разъем Высококачественная универсальная PLC разрывная
Новая Клеммная колодка в японском стиле SiRON T044 40-контактный разъем Высококачественная универсальная PLC разрывная

Новая Клеммная колодка в японском стиле SiRON T044 40-контактный разъем Высококачественная универсальная PLC разрывная


Поделиться:

Цена:*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Specification


input
Nominal operating current ：1A
Nominal coil voltage：DC24V
Corresponding output Devices
Button Switch,Photoelectric Switch, Servo motor control Button Switch,Photoelectric Switch,Solenoid, Indicator,Stepping Servo
Motor,etc.
Installation method
DIN Rail
Connection mode of terminal board
screw
Suitable cable
X210-4 X200-4 X210-5 X218-6 (For detail ,please refer to the directory cable series
Suitable PLC(In addition to the listed products,other same number PLC module can also be corresponding).
KEYENCE ：
KV-1000 KV-3000 KV-5000 KV-H20S KV-H40S
Panasonic：
FPG-XY64D2T/P FP2-C1D .
FP2-X32D2  FP2-X64D2
FP2-32T/P   FP2-Y64T/P
FP2-XY64D2T/XY64D7T
FP2-XY64D2P/XY64D7P
FP2-PP21    FP2-PP22
FP2-PP41    FP2-PP42
FP2-HSCT   FP2-PXYT
OMRON：
CJ1W-ID231 CJ1W-OD232
CJ1W-ID261 CJ1W-OD233
CJ1W-MD261 CI1W-OD262
CJ1W-ID232 CI1W-OD263
CI1W-ID262 CJ1W-MD263
CJ1W-MD263 CJ1W-MD563
CJ1W-MD563 CJ1 M-CPU21
CJ1W-OD231 CJ1 M-CPU22
CJ1W-OD261 CJ1M-CPU23
CJ1W-MD261
MISUBISHI：
QX41 QX72 QX41-S1
QY41P QX42 QY42P
QX42-S1 QY71 QX71
QH42P QD70P4 QD70D
QD70P QD75M
SIEMENS： 40P Plug with a full range
Yokogawa： F3WD64-3N F3WD32-3F F3WD64-3F
 weight
155g


Features



1.T044 is a 40pin terminal connection for 40pin connector,suitable to all PLC
connections with 40pin MIL plug on the market,small size for space saving.
2.The products are minimum space design of the Intra-industry.

Precautions：
Before ordering，please confirm the PLC pin definition,choose the suitable terminal.When PLC connection,please be sure to use the company developed and the corresponding special cable.
Screw Mounting:use M4*16 screw,screw hole depth≥3mm.
DIN Rail Mounting:Standard 35mm DIN RAIL.


Product Description




Company Profile






Certifications




Delivery




FAQ


Q1: What company do we belong to?
A1: We are a manufacturer and a trader.

Q2: How long is our delivery time?
A2: This depends on the quantity of the goods you ordered, we have stock, usually 15-20 days delivery time.

Q3: How to order?
A3: Please mail your order or request to us, and tell us the following information: shipping details, including company name, address, person, phone number, quantity.

Q4: How many discounts are available for ordering products?
A4: As long as you provide us with your demand, we will give you the best price.
