Product Overview
RicherLink gigabit L2 managed switch RL-S7210GF provides 8 10/100/1000Mbps ports and 2 gigabit SFP slots. The switch provides security performance, quality of services, flexibly layer 2 management features. Moreover,with 2 gigabit SFP slots expands your network flexibly.
RL-S7210GF supports a complete lineup of layer 2 features, including 802.1Q tag VLAN, Port Isolation, Port Mirroring, Storm Control, STP/RSTP, Link Aggregation Control and 802.3x Flow Control function. Any more, the switch provides advanced features for network maintenance. Such as Self-Loop Back Detection, IGMP Snooping . IGMP snooping ensures the switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Self-Loop Back Detection detect two ports direct link or the network loops on single port, Self-loop and RSTP function provide a secure and stable network environment, to achieve complete loop-free network .
RL-S7210GF is easy to use and manage. It supports various user-friendly standard management features，such as intuitive web-based Graphical User Interface(GUI) or Command Line Interface(CLI). SNMP (v1/2c) and RMON support enables the switch to be polled for valuable status information and send traps on abnormal events.
Another important feature is RL-S7210GF supports RPS power function.and the adapter power can charge for the redundancy battery power.
RL-S7210GF supports a complete lineup of layer 2 features, including 802.1Q tag VLAN, Port Isolation, Port Mirroring, Storm Control, STP/RSTP, Link Aggregation Control and 802.3x Flow Control function. Any more, the switch provides advanced features for network maintenance. Such as Self-Loop Back Detection, IGMP Snooping . IGMP snooping ensures the switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Self-Loop Back Detection detect two ports direct link or the network loops on single port, Self-loop and RSTP function provide a secure and stable network environment, to achieve complete loop-free network .
RL-S7210GF is easy to use and manage. It supports various user-friendly standard management features，such as intuitive web-based Graphical User Interface(GUI) or Command Line Interface(CLI). SNMP (v1/2c) and RMON support enables the switch to be polled for valuable status information and send traps on abnormal events.
Another important feature is RL-S7210GF supports RPS power function.and the adapter power can charge for the redundancy battery power.
Product Specification
ITEM | Description |
Interface | 8 10/100/1000Mbps RJ45 Ports(Auto Negotiation/Auto MDI/MDIX) |
2 1000Mbps SFP Slots | |
1 Console Port | |
Bandwidth/Backplane | 20Gbps |
MAC Address Table | 8K |
Packet Forwarding Rate | 14.9Mpps(64-byte packets) |
Jumbo Frame | 9k Bytes |
QoS | Support 802.1p CoS/DSCP priority |
Support 8 priority queues per port | |
Queue scheduling: strict priority(SP), deficit weighted round-robin scheduling(DWRR) | |
Full-duplex flow control (IEEE 802.3X) and half-duplex backpressure | |
STP | Standard Spanning Tree 802.1d(STP) |
Rapid Sanning Tree 802.1w(RSTP) | |
VLAN | Supports up to 16 VLANs simultaneously (out of 4K VLAN IDs) |
802.1Q tag-based VLAN | |
Port-based VLAN | |
Port Isolation | |
Management VLAN configuration | |
IGMP Snooping | Support IGMP Snooping V1/V2 for multicast groups |
Port mirror | Per-port ingress and egress mirroring |
Trunking | Static trunk (Link Aggregation) |
Up to 5 groups | |
and Up to 10 ports per group | |
Broadcast Storm Control | Generic storm controllers for flooded broadcast, flooded multicast, and flooded |
unicast traffic | |
Loop detection | Support the loop detection for easy maintenance method to solve network failure |
problem. | |
Management | Web-based GUI and CLI management |
SNMP v1/v2 | |
RMON (1, 2, 3, 9 groups) | |
Firmware Upgrade: TFTP & Web | |
Dual Image | |
Power | 9-15V /1A |
RPS Power | 12V battery |
Environment | Operating Temperature: 0℃~40℃ (32℉~104℉); |
Storage Temperature: -40℃~70℃ (-40℉~158℉) | |
Operating Humidity: 10%~90% non-condensing | |
Storage Humidity: 5%~90% non-condensing |
