Products Description
Products name | Aluminum plate |
Thickness(mm) | aluminum sheet:0.15-6.0 aluminum plate:6.0-25.0 |
Width(mm) | 20-2000 |
Standard | GB, JIS, DIN, ASTM |
Surface treatment | Brushed, Mirror, Embossed, Sandblasted, etc |
Temper | O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34/H16/H26/H36 H18/H28/H38 H114/H194, etc. |
Type | coil/sheet/strips/plate |
Package | Standard export package,such as wooden box or as required. |
1000 Series | Industrial Pure Aluminum(1050,1060 ,1070, 1100) |
2000 Series | Aluminum-copper alloys(2024(2A12), LY12, LY11, 2A11, 2A14(LD10), 2017, 2A17) |
3000 Series | Aluminum-manganese alloys(3A21, 3003, 3103, 3004, 3005, 3105) |
4000 Series | Al-Si alloys(4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A) |
5000 Series | Al-Mg alloys(5052, 5083, 5754, 5005, 5086,5182) |
6000 Series | Aluminum Magnesium Silicon Alloys(6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02) |
7000 Series | Aluminum, Zinc, Magnesium and Copper Alloys(7075, 7A04, 7A09, 7A52, 7A05) |
Mechanical Property | ||||||||||||||||
ALUMINUM ALLOY | Grade | Normal Temper | Temper | Tensile Strength N/mm² | Yield Strength N/mm² | Elongation% | Brinell Hardness HB | |||||||||
Plate | Bar | |||||||||||||||
1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 | ||||||||
1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 | |||||||||
Al-Cu (2XXX) | 2019 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - | ||||||||
2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 | |||||||||
Al-Mn (3XXX) | 3003 | O,H112,H | O | 110 | 40 | 30 | 37 | 28 | ||||||||
3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 | |||||||||
Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 | ||||||||
Al-Mg (5XXX) | 5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 | ||||||||
5083 | O,H112,H | O | 290 | 145 | - | 20 | - | |||||||||
Al-Mg-Si (6XXX) | 6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 | ||||||||
6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 | |||||||||
Al-Zn-Mg (7XXX) | 7003 | T5 | T5 | 315 | 255 | 15 | - | 85 | ||||||||
7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 | |||||||||
Application
Company Profile
SHANDONG HENGYUAN GROUP
Shandong Hengyuan Materials(grpoup) Co., Ltd. is locate in Jinan, provincial capital of Shandong province.
Hengyuan are engaged in providing wide range of steel products. We specialized in stainless steel products and aluminum products. And various material are optional as hot rolled steel ,cold rolled steel ,galvanized steel , checkered steel , ppgi steel aluminum zinc coating steel etc .
Hengyuan are engaged in providing wide range of steel products. We specialized in stainless steel products and aluminum products. And various material are optional as hot rolled steel ,cold rolled steel ,galvanized steel , checkered steel , ppgi steel aluminum zinc coating steel etc .
