Цена:1 499,00 $ - 1 999,00 $*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Specification


Vehicle Basic Parameters
External Dimension(L x W x H)
3.50m(L) x 1.3m(W) x 2.08m(H)
Nos of Passenger
1
Rear Tread
980
Wheel Base(mm)
2380
Max Mileage(Without Load) (Km)
80
Max Speed(Without Load) (Km/h)
25
Min Turning Radius(m)
3
Max Turning Angle(Degree)
45
Gradeability
>=10 degree
Volume of Garbage Container (Cubic Yard)
About 2.64 (2m L x 1.2m W x 1.1m H)
Vehicle Weight (Kg)
About 1050
Rated Load(Kg)
1000
Ground Clearance(mm)
130mm
Min Braking Distance(m) at V=20Km/h
4
Tyre size
F:400-12 , R: 450-12
Max Tipping Angle
50 degree
Vehicle Body Configurations
Chassis
Heavy duty, with hydraulic braking systems
Front Wind Shield
Steel cabinet, with wiper
Floor
Anti-slippery rubber pad
Dashboard
Plastic cover, with speedo meter, battery indicator, current meter, combination buttons, etc.
Mirrors
Available
Lamps and Signals
Headlamp, left/right indicators in front and rear, position lamp, brake lamp, horn and reverse buzzer
Garbage Container
The whole lining inside container is made of SS steel
Dustbin Lifting Mechanism
Hydraulic operated self-locking and pressing lifting system, easy to operate
Compactor
Available
Electric Components
Battery capacity
72V 120Ah Gel SMF battery(li-ion battery optional)
Driving Motor
72V 2.5KW motor
Charger
72V 15Ah auto-cut charger, 8 hours to full charge
Hydraulic System
Hydraulic Cylinder for Tipping
As per vehicle
Hydraulic Cylinder for Compactor
As per vehicle
Motor for Pump
72V 800W DC motor
Hydraulic Pump Pressure(Mpa)
As per vehicle
Control Voltage(VDC)
12
Oil Tank(L)
As per vehicle
Tipping Process Duration(S)
12
Dustbin Loading&unloading CT(S)
10


Details Images




Our Service


Pre-sale: Customer manager 24 hours on-line service. Reply inquiry with in 5 minutes.
In-sale: Production process transparency And provide pictures and videos for productions process and schedule.
After -sale: Visit customers regularly, enquire customers‘ satisfaction, 0 claims.
Quality: 3 times of quality checking from raw material receiving to finished product, 100% inspection, quality acceptance above 99%.


Certifications




Customer Photos




Payment & Transportation




FAQ


Q. Can we visit your company/factory before place the order?
A: It's our pleasure. We sincerely welcome you to visit, and we guarantee that you will have a pleasant journey in China!
Q.How can you guarantee the production quality ?
A. After production, we'll process the physical and chemical tests for our current products as well as development new products. Our product quality are guaranteed by Wuhan Metallurgical Institute and Guangzhou Institution of Metal Research, the long term cooperation with them can save a lot of testing time for customers.
Q.What about the package?
A. It can make as the you need and depend on the products shapes. Generally, we can provide iron drum, carton, wooden case, and bag packages.
Q: How long is the delivery time?
A: Generally. It depends on quantity and the way of transportation.
