120VAC 190 мм центробежный вентилятор с загнутыми назад лопатками C2S-190.45A для в ванную комнату

Описание и отзывы

Характеристики



Jasonfan 120VAC 190mm backward curved centrifugal fan C2S-190.45A for Bathroom Ventilation and Kitchen Ventilation



Specification:

• Motor Structure: Cage type capacitor structure external rotor motor with automatic recovery thermal protector


• Blades: Made by injection mould with black plastic PBT+30% glass fiber + VO class of anti-flaming liquid.


• Bearing Type: Maintain-free ball bearing


• Insulation Isolation Grade: F          Protection Grade: IP44


• Dielectric Withstand Voltage: AC 1800V, at 0.5mA, 50/60Hz


• Allowable Ambient Temperature: -40 to +80 Centigrade degree (ball bearings) & (Under unconcretionary)


• Noise Lever: 58-59dB at normal operation


• Life: 50,000hours


• Connection way: UL3266-18 Terminal block connection


• Unit weight: 1.27kg


• Certificates: UL E476782,CE,CCC

Specifications
Category	Backward Curved Centrifugal Fan
Type	C2S-190.45PL
Rated Voltage	115V
Frequency	60Hz
Current	0.65A
Input Power	71W
Speed	2700RPM
Max Air Flow	620m3/h
StaticPressure	420Pa
Noise	61dB
Weight	1.27KG
Color	Black
