Гидравлический гусеничный экскаватор MAXIZM 313D2GC С КРЕПЕЖНОЙ молоточной


Поделиться:

Цена:5 157 194,56-5 880 165,76 ₽*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики


Perfect Quality Best Choice Crawler Excavator 13T 313 Towable Backhoe China Micro Digger At The Wholesale Price



CONTACT US


Welcome to MAXIZM Construction Machinery Co.,Ltd!


Home of value that works!


We provide you with the best quality of BULLDOZER, EXCAVATOR,COMPACTOR, FORKLIFT, MOTOR GRADER,WHEEL ROADER,ETC.





Jerrica Liu


Phone Number:+86-18246243847


EMAIL:jerrica@maxizm.com





  • Increased breakout forces and hydraulic power increase productivity by up to eight percent over the previous model.

  • The advanced hydraulic system provides the optimum balance of power and efficiency while giving you the control you need for precise digging requirements.

  • Reduce fuel consumption by up to five percent over the previous model.

  • Match your machine to the job with power modes. Let Smart mode automatically match engine and hydraulic power to working conditions. Power mode constantly provides maximum productivity, and ECO mode minimizes fuel consumption in less-demanding applications.

  • Get higher production in demanding applications, easier penetration into piles, and faster cycle times with Advansys bucket tips. Quickly change tips with a simple lug wrench instead of a hammer or special tool, improving safety and uptime.

  • Auxiliary hydraulic options give you the versatility to use a wide range of  attachments.

  • The  C4.4 engine meets U.S. EPA Tier 4 Final emission standards.

  • Don’t let the temperature stop you from working. The 317 has an optional cold-start capability of -25°C (-13°F).








Product Overviews



















































































































































































































































































Parameter313315317
Engine
Net Power (kW)80.997
Engine ModelC3.6C4.4
Engine Power (kW)8298
Bore (mm)98105
Stroke (mm)120127
Displacement (L)3.64.4
Hydraulic System
Main System-Maximum Flow (l/min)247276296
Max. Pressure-Equipment (kPa)35000
Max. Pressure- Travel (kPa)2500035000
Max. Pressure- Swing (kPa)260002600025800
Swing Mechanism
Swing Speed (r/min)11.5128.7
Max. Swing Torque (kN·m)353564
Weights
Operating Weight (kg)138001540018200
Service Refill Capacity
Fuel Tank Capacity (L)258187271
Cooling System (L)1528
Engine Oil (L)815
Final Drive - Each (L)36
Hydraulic System - Including Tank (L)14513894
Hydraulic Tank (L)707287
DEF Tank (L)2122
Dimensions
Boom (m)Reach 4.65 mReach  5.1 m
StickReach R3 mReachR2.9 m
Bucket (m³)GD 0.53 GD 0.76
Shipping Height - Top of Cab (mm)28102930
Handrail Height (mm)281028602940
Shipping Length (mm)805075308570
Tail Swing Radius (mm)219015702500
Counterweight Clearance (mm)9158801010
Ground Clearance (mm)445440430
Track Length (mm)37503970
Length to Center of Rollers (mm)30403170
Track Gauge (mm)1990
Transport Width (mm)24902690
Working Ranges & Forces
Max. Digging Depth (mm)604059906400
BoomReach 4.65 mReach 5.1 m
StickReach R3 mReach 2.9 m
Bucket(m³)GD 0.53GD 0.76
Max. Reach at Ground Level (mm)866086909010
Max. Cutting Height (mm)883096908900
Max. Loading Height (mm)642072206280
Min. Loading Height (mm)160020801990
Max. Depth Cut for 2440mm (8ft) Level Bottom (mm)586058106170
Max. Vertical Wall Digging Depth (mm)519051804960
Bucket Digging Force - ISO (kN)98.6798.67123

Stick Digging Force - ISO (kN)


59.2975





  • Increase operator productivity with an all-new, larger cab.

  • Get in and out of the cab easier using the tip-up left console.

  • Advanced viscous mounts reduce cab vibration.

  • Control the excavator comfortably with easy-to-reach controls all located in front of you.

  • Stow your gear with plenty of in-cab storage beneath and behind the seat, overhead, and in the consoles. A cup holder, document holder, and coat hook are also provided.

  • Use the standard radio’s USB ports and technology to connect personal devices and make hands-free calls.





  • Expect up to 20 percent less maintenance costs over the previous model.

  • Quickly check and service your machine with all daily maintenance points accessible from ground level.

  • Check the engine oil level quickly and safely from the ground. Fill and check engine oil on top of the machine with a conveniently located second dipstick.

  • Track your machine’s filter life and maintenance intervals on the in-cab monitor.

  • The new hydraulic oil filter provides improved filtration performance, anti-drain valves to keep oil clean when the filter is replaced, and longer life with a 3,000-hour replacement interval – 50 percent longer than previous filter designs.

  •  ports are located at ground level, simplifying maintenance and allowing for quick, easy extraction of fluid samples for analysis.

  • 320C_8.jpg323D_4.jpg349_1.jpg349_5.jpg

  • 1.png
