Product Description
P860 Nitrogen Oxygen Analyzer Portable Oxygen Purity Analyzer 100ppm~21%
P860 Nitrogen Oxygen Analyzer Portable Oxygen Purity Analyzer 100ppm~21%
P860 series analyzer is the online intelligent measurement instrument, which adopting advanced ion current oxygen sensor with single chip technology. N2%=100%-O2%. It has been widely used in the fields of nitrogen separation from air, fertilizer, petrochemicals and biological fermentation.
Features
- New pattern long-life conversion ion current tester with fast response and high sensitivity
- N2 or O2 concentration display
- Checking the sensor working state automatically and unique double-line working change mode extending the sensor’s life
- Setting alarm value freely
- High precision, automatic temperature compensation, eliminating the impact of environmental temperature
Technical Specificat
CI-PC36 300ml/min Gas Portable Dew Point Analyzer 1000ppm 21% O2
| Measure range: | Basic type:-60~+20°CStandard type:-80~+20°CExtended type:-100~+20°C |
| Accuracy: | ±3°C(-80~-60°C)±2°C(-60~+20°C) |
| Repeatability: | ±0.5°C |
| Zero drift: | ±1%FS/7d |
| Range drift: | ±1%FS/7d |
| Response time: | At the temperature of +20°C and pressure of 1 bar, the range reaches 63% [90%] -60-*-20°C Td 5s[10s]-20--60°C Td 45s[10min] |
| Power supply: | 85~264VA,50/60Hz |
| Environment temperature: | 0~45°C Environment Humidity:<90%RH |
| Sample temperature: | 0~50°C |
| Sample gas pressure: | atmospheric conditions+10% (Gas outlet should be atmospheric conditions) |
| External control signal: | 1 set,control signal:9~28VDC (optional) |
| Analog output: | Standard configuration set of 4-20mA,0-20mA and 0-10V can be set by menu |
| Communication: | RS485(standard)/RS232(optional) |
| Alarm output: | 2 sets |
| Relay contact point capacity: | 24VDC,0.2A |
| Inlet and outlet: | 1/4 inch NPT internal thread,standard 6.5 hose joint |
| Instrument size: | WxHxD=144mx144mmx251 mm |
| Installation hole size of instrument: | LxW=136mmx136mm |
Certifications
Why Choose Us
Strong technology research and development team
Cape Golden relies on the technology advantage of Tsinghua University, Chinese Academy of Sciences and China Agricultural University, with more than ten years experience of air separation and agricultural irrigation technology, now we could meet customers’ different requirements in various fields, we always insist on providing economic, reliable, efficient and standard instruments and service.
Perfect production quality assurance measures
Beijing Cape Golden Gas System Company LTD., conducts quality control management in production process, in accordance with the ISO9001: 2000 quality management system standard, including: 1. Clear the customer's requirements, provide perfect, reasonable technology solutions 2. contract review 3. design control 4. Spare parts procurement, outsourcing processing control 5. manufacturing control 6. The factory inspection 6. Equipment packing and shipping control
Delicate and careful on-site training and after-sales service
Cape Golden provides on-site training for each sold product and after-sales service, on-site training is for unlimited time, for the customers to completely understand the indicators of the products. After-sales service hotline for 7*24 hours, to guide the customer problems at any time. The 37 after-sales service personnel provide on-site service for global customers. Since the Company’s establishment, there is not one case of after-sales service complaint, our company gets customers in various areas of the world high praise.
Packing & Deliver
Product Description
FAQ
1.Q:Where is your factory located? How can I visit there?
A:We are the professional gas equipments, founded in 2008. Our factory is located in Beijing China . Welcome to visit us!
2.Q:What’s your delivery time?
A:As usual 40 days,if urgently order,pls contact our sales in advance.
3.Q:How does your factory do regarding quality control?
A:Quality is everything. we always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001 and CE certificate.
4.Q:What's payment term?
A:T/T, L/C etc.Also we could accept USD, RMB, Euro and other currency.
5.Q:How about your after-sales service?
(1) Provide customers with installation and commissioning online instructions.
(2) Well-trained engineers available to overseas service.
(3) Worldwide agents and after service available.
