1 кВт 2 мини-инвертор для кондиционера Гибридный инвертор Заряда Mppt контроллер бытовой светодиодной лампы и
- Категории: >>>
- Поставщик: Beijing,Multifit,Electrical,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Specification
Technical parameters: | ||||||||
Type(unit) | SuninvM MPPT 1K 24V | SuninvM MPPT 2K 48V | SuninvM MPPT 3K 48V | SuninvM MPPT 5K 48V | ||||
Rated capacity | 1KVA | 2KVA | 3KVA | 5KVA | ||||
Battery rated voltage | 24V | 48V | 48V | 48V | ||||
PV maximum input open voltage | 225V | 225V | 225V | 225V | ||||
MPPT voltage range | 100V | 150V | 150V | 150V | ||||
Voltage range | 110/220VAC ±15% | |||||||
Frequency | 50/60Hz | |||||||
Rated charge current | 30A | 30A | 30A | 30A | ||||
Rated output voltage | 110/220V ±15% | |||||||
Rated output frequency | 50/60Hz ±1% | |||||||
Rated output current | 5.5A | 9.1A | 13.6A | 22.7A | ||||
Output power factor | ≥0.8 | |||||||
THD | <3% | |||||||
Output wave | Sine wave | |||||||
Output phase | Single phase | |||||||
Peak factor | 3:1 | |||||||
PV charge current | 2*20A | 2*20A | 2*30A | 2*50A | ||||
Efficiency | ≥90% | |||||||
Dynamic response | 5% (load from 0 to 100%) | |||||||
Noise level | ≤40dB (1m distance) | |||||||
Display interface | LCD | |||||||
Communication interface | USB | |||||||
Environmental temperature | -30+55℃ | |||||||
Environmental humidity | 10%-90% （non condensing） | |||||||
Protection level | IP21 | |||||||
Protection function | Array/ Over voltage/ Over current/ Short circuit/ Reverse connection ect protection function | |||||||
Altitude (m) | ≤2000 ( above 1000m need according GB/T3859.2 to derate operating) | |||||||
Dimensions (mm) | 420*640*210(W*H*D) | |||||||
Weight (kg) | 20 | 25 | 25 | 30 | ||||
Warranty | 2 years | |||||||
Certificate | CE/ ISO9001 | |||||||
Product Details
Engineering Cases
Related Products
Certifications
About MULTIFIT
MULTIFIT was founded in 2009, based on providing the world-class small-scale photovoltaic power plants for civilian solutions and innovative research and development of renewable energy electrical products, we have cultivated a group of sales and R&D teams with ideals, experience and technology. The product has obtained more than 10 patent certificates, which has been exported to Europe, America, Africa, and Latin America etc, more than 50 countries and regions in the world.
Come with MULTIFIT, to power a better world !
Exbihition Shows
FAQ
Q1: Are you a factory or trading company?
A: We are a factory. Multifit Solar is an original design manufacturer of power inverter, the solar charge controller and solar
array box since 2009.
Q2: Where is your factory located? How can I visit there?
A: Our factories are located in BeiJing and Shantou City, Guangdong, China. Its takes half hours from Airport or Train Station. Welcome to visit our technology development and production lines at your free time!
Q3: How can I get some samples?
A: We can provide you samples for quality checking. Kindly contact us for getting more discount and profitable project solutions.
Q4: How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. Airline and sea shipping also optional.
Q5: Where is your loading port?
A: Multifit have 2 factories in Beijing and Shantou City Guangdong. The loading port is TianJin/ Shanghai or Shenzhen/ Guangzhou for optional.
Q6: How long is your factory delivery time?
A: 3-7 days for sample order, 5-10 days for MOQ order,15-30 days for 20ft container.
Q7: Is it OK to print my logo on the product?
A: Yes. Please inform us formally before production and confirm the design firstly based on our sample.
Q8: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
