9 0 м Ku band моторизованная спутниковая

ELECTRICAL SPECIFICATON

Type

YDT-900

Band

C-Band

Ku-Band

Operating Frequency. GHz

Receive

Transmit

Receive

Transmit

3.4~4.2

5.85~6.725

10.95~12.75

13.75~14.5

Gain, Mid-band, dBi

49.9

53.5

59.4

60.8

Polarization

Linear/Circular

Linear

XPD(on Axis), dB

35

35

35

35

XPD across 1dB Beam Width, dB

33

33

33

33

Axial Ratio (Circular-Polarized)

1.30/1.06

1.09/1.06

VSWR

1.25

1.25

1.25

1.25

Antenna Noise Temperature

10°Elevation

30°Elevation

50°Elevation

35°K

26°K

24°K

60°K

50°K

48°K

-3dB Beam Width, Mid-band          -3dB

0.55°

0.4°

0.19°

0.16°

Typical G/T(El >10°)                 G/T

30.5dB/K°

(30°LNA)

37.3dB/K

(70°LNA)

Tx.Power Capability. KW

5

2

Feed Interface

CPR-229G

CPR-137G

WR-75

WR-75

Feed Insertion Loss, dB

0.2/0.3

0.2

0.2/0.4

Isolation, Tx to Rx, dB

85

Side lobe

CCIR 580-4
