Прошитый стежок Durkopp на цепочке автоматическая отделка компьютеризированная машина для стегания с одной иглой простыня


Поделиться:

Цена:*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Product Description




Specification


1.Equipped with DURKOPP sewing head, operation speed will be greatly improved,the maximum speed up to 2500RPM
2.Adoppted imported large rotary hook,360° jump quiltting availble.
3.Automatic disconnection detection.
4.Presser Foot can be adjusted according to material thickness.
5.Windows xp computer system control, make quilting with high precision even be various of complex patterns
6.Large capacity memory,pattern storage more than 100,000.
7.Automatic yield calculation
8.Pattern effect display and process path display
9.Real time data protection,go on working in the original position after machine down time
10.Full automatic lifting and edge cutting
11.Professional pattern-designing software,scan and input with BMP graphics printing and CAD drawing .
12.Automatic Fabric Feeding and Tensioning


Model
GM-DZ5
Overall(Lx WxH)
9900x3800x1600mm
Quilt thickness
≤80mm
Over all weight
3000kg
Quilt width
≤2400mm
Rotation speed
3000rpm
Production speed
70-200m/h
Stitch
2-6mm
Power
8.0kw
(AC)Rated voltage
380v/220V 50Hz/60Hz
