Description:

Dry granulator,Absorbed foreign advanced technique of powder granulator, improved and heightened on the basis of foreign technique, this dry-type granulator is developed by our factory. It has more reasonable and compact structure, simply technological processes, easy operation and better performance. Powder materials can be made into even granules customer needs without adding any bonding agent when they run through the machine. As density of granules are larger, no any afterward process is needed so as to reduce technological process, reduce granulation cost and powder pollution and improve labor environment as well.





Work Principle:

Vertical Feed Set After weight measured powder materials are sent laterally by the vibration hopper to the main feeder, deaerated by the stirring screw of the main feeder, pre-pressed and pushed into the arc grooves of left and right rollers. Driven by a pair of meshed gears, two rollers rotate in opposite direction with same speed, and powder materials are pressed into dense sheet while they run through rollers. Under the function of elastic recovery after rollers, they'll be separated from rollers and drop down, and fewer sheet not dropped will be scrapped off by the blade. Stripe grooves evenly distributed on the surface of rollers can prevent sliding when powder materials are fed into rollers. After crushed and granulated, they'll pass through the vibration sieve to be graded, and granules which meet requirement can be obtained. Powder after the sieve will return to the vibration hopper to be granulated circularly.



Product Characteristics:

1. Making granules from dry powder directly without any bonding agent.

2. The strength of granule can be adjusted by pressure of rollers so as to control strength of granule.

3. Sand-shaped irregular granules are produced.

4. Large productive capability due to continuous production. High degree of automation to suit automatic production.



Application:

Except those dangerous materials that are subject to explosion due to crushing and rubbing, most part of dry power materials can be directly granulated by this machine. If water-cooling is adopted for rollers by turning connectors, this machine can also be suited for granulation of heat sensitive materials.



Technical Parameter:



Item	Type
	GL240-80	GL240-160	GL300-250	GL360-300	GL450-350
Diameter of roll (mm)	Φ240	Φ240	Φ300	Φ360	Φ450
Width of roll (mm)	80	160	250	200	350
Max pressure of roll (t)	50	60	80	100	130
Revolution of roll (rpm)	8-20	8-20	8-20	8-20	8-20
Max thickness of roll (mm)	4	5	6	8	8
Capacity of pressed pill (kg/h)	250-500	500-900	700-2000	1000-4000	2000-7400
Productive capacity (kg/h)	80-150	150-300	300-600	600-1000	1000-2000
diameter of finished products (mm)	0.2-5	0.2-5	0.2-8	0.2-8	0.2-8
Main motor power (kw)	7.5	11	18.5	30	45
Total power (kw)	11.5	17	28	43	60
Overall dimension (mm)	1500×1800× 3500	1500×2000× 3800	1800×2000× 4000	2000×2200× 4200	2200×2500× 4500
Weight (t)	5	6	8	10	13





1.Factory Tour:





2.Factory Certificate:





3.Our customers:



1.Customer plant installation:
