Product Description
China HTLP-06 self lifting platform
Self-propelled scissor lift has its own walking and lifting function, with the steering wheel to control the direction of running, speed can walk and a brake device, battery driven DC motor running and movements, may also choose to AC motor or diesel engine running and movements, can also use wireless electronic remote control movements, without the need for manual traction and does not need an external power supply, flexible and convenient in movement, high-altitude operations more efficient and convenient is modern enterprise, safety production ideal high-altitude operations equipment.
Specification
Model | HTLP-06 |
Safe working load | 320kg |
Max working height | 6m |
Overall size | 2600*1170*2160mm |
Platform size | 2400*1170mm |
Platform extension size | 0.7m |
Wheelbase | 1.89m |
Driving motor | 24v/4kw |
Traveling speed | 3.5km/h |
Up/down speed | 80/90 sec |
Battery | 6V/230Ah |
Charger | 24V/25A |
Max climb capability | 25% |
Max working angle | 2°/3° |
Operate weight | 2200kg |
