Multifunctional Self- priming Corn Wheat Flour Mill Milling Grain Crusher Machine Wheat/Maize/Rice Grain Grinding Mill
Product Overview
The toothed claw crusher is a multi-functional crusher, which can select self-priming feeding. The internal part of this series of crushers is a toothed nail type crusher claw, which has a wide range of crushed materials, energy conservation and environmental protection, and high production efficiency. The crusher can crush all kinds of coarse grains into powder without leaving any residue. This machine can process chemical raw materials, such as Chinese herbal medicine, gypsum powder, fish bone powder, metal calcium and other materials. The crushing fineness is adjustable. It is a multi-functional crusher with a wide range of crushed materials, No residue is left in the crushed materials. The multi-functional crusher has different feeding methods, including vertical, inclined and self-priming feeding, which can be purchased according to your requirements.
Specifications
Model | Power(kw) | Capacity(kg) | Weight(kg) | Size(mm) |
BD-ZX200 | 3 | 100-150 | 35 | 400* 550*550 |
BD-ZX300 | 4 | 200-300 | 50 | 550*580*400 |
BD-ZX320 | 7.5 | 500-1000 | 110 | 950*650*1050 |
BD-ZX360 | 11 | 1000-1200 | 130 | 1050*750*11 50 |
BD-ZX400 | 15 | 1200-1500 | 160 | 1250-750*1200 |
BD-ZX450 | 18.5 | 1500-2000 | 230 | 1350*850*1300 |
BD-ZX600 | 22 | 2000-2500 | 380 | 1450*950* 1350 |
Detailed images
During operation, the processed materials enter the crushing chamber from the hopper and are cracked by the high-speed rotating working parts. At the same time, the movement direction of the materials is changed. Because the high-speed rotating working parts destroy the deposition of the material layer, the materials move with the rotor. In this process, the particles are repeatedly impacted by the working parts and the machine body, as well as the collision and friction between the particles, so that they are gradually crushed until their geometric diameter is smaller than the diameter of the sieve hole. Under the action of centrifugal force and air flow, the crushed materials leak into the powder chamber through the sieve hole and are discharged from the discharge port.
Final Production
Packing&Shipping
1. Packing:Standard wooden case.
2. Delivery time: Within 15 workdays after getting the down payment.
3. Payment: 50%TT payment in advance, 50%TT pay the balance before delivery.
4. Warranty: One year.
2. Delivery time: Within 15 workdays after getting the down payment.
3. Payment: 50%TT payment in advance, 50%TT pay the balance before delivery.
4. Warranty: One year.
