Product Description
· 5Watts power output
· UHF 400-480MHz
· 2600mAh 7.4V big capacity
· Big speaker, loud sound
· LoRa mesh network
· Each radio has repeater function
· New generation DMR radio
Model | MYT-836L | |
General Specifications | ||
Working Voltage | 7.4V DC ±20% | |
Working Temperature | -25℃~ + 60℃ | |
Number of Channels | 16 | |
Dimensions: (mm) | 117 x 52 x 61 (mm) | |
Weight: (g) | 240g | |
Transmitter Specifications | ||
Frequencies - Full Bandsplit | UHF:400-480MHz | |
Frequency Stability(-25 to 55, 25 Ref) | 1.25ppm | |
Power Output | 5W | |
Modulation Limiting | ±≤5KHz@25KHz | |
FM Hum & Noise | 45dB@25KHz | |
Conducted/Radiated Emission | -36dBm < 1GHz, -30dBm > 1GHz | |
Adjacent Channel Power | <-65dB @ 25KHz | |
Audio Distortion | < 5% | |
Receiver Specifications | ||
Sensitivity(12 dB SINAD)EIA | 0.20μV@12.5KHz/25KHz typical | |
Intermodulation EIA | 60 dB | |
Adjacent Channel Selectivity | 65 dB@20/25KHz | |
Spurious Rejection | 65 dB | |
Rated Audio | 1W | |
Audio Distortion @ Rated Audio | 5% @ 1W | |
Audio Response (300-3000Hz) | +3 ~ -3 dB | |
Conducted Spurious Emission | -58 dBm<1 GHz, -47 dBm>1GHz | |
