Сварочный аппарат импульсный MIG MAG для роботизированной руки 350A

350 A MIG MAG Welding Machine for Robotic Arm

682*380*612mm

1. Full digital system to achieve excessive drop precise control, to achieve continuous and stable welding quality.
2. Soft switch inverter technology, can improve the reliability of the whole machine, energy saving.
3. Full digital high-precision wire feeding control system, two drive two slave encoder full digital control wire feeding device, even if the power supply voltage, wire feeding resistance and other external factors change, still ensure the wire feeding stability.
4. With a unified/separate adjustment mode, convenient adjustment to meet the use of different types of robots and special aircraft.
5. Arc starting and arc closing parameters are adjustable, and the welding quality is high.
6. Suitable for welding all kinds of carbon steel workpiece.

Input Voltage

3PH 380V±10%, 50Hz

Rated output

350A/31.5V

Applicable Welding wire

Solid Wire/ Flux Wire

Wire Diameter

0.8-1.6mm

Duty Cycle (40°C)

60%;

Welding material @Pulse Mode

Carbon steel, Stainless steel

Welding material

Protection Class

IP23

Torch Cooling

Air/Water

Welding Current

40-350A

Output Voltage

16-35.5V

Power Factor

≧0.80

Fre.HZ

50/60

Gas Flow Rate

15-20L/min

Dimensions

682*380*612mm

Weight

60kg
