Junai Ceramic Fiber Cloth & Belt | ||||||||||
Product Name | Refractory Fiber Cloth | Refractory Fiber Belt | ||||||||
Product code | CFC | CFT | ||||||||
Reinforcing material | steel wire | glass fiber | steel wire | glass fiber | ||||||
melting point(℃) | 1760 | 1760 | 1760 | 1760 | ||||||
Classification temperature(℃) | 1260 | 800 | 1260 | 800 | ||||||
Working temperature(℃) | 1000 | 650 | 1000 | 650 | ||||||
Bulk density(kg/m³) | 500 | 500 | 500 | 500 | ||||||
Fiber diameter(μm) | 3~5 | 3~5 | 3~5 | 3~5 | ||||||
Ultimate strength(kPa) | 400 | 400 | 400 | 400 | ||||||
Organic content(%) | ≤15 | ≤15 | ≤15 | ≤15 | ||||||
Moisture content [without reinforcement](%) | ≤2 | ≤2 | ≤2 | ≤2 | ||||||
Loss on ignition(%) | 15~25 | 15~25 | 15~25 | 15~25 | ||||||
Warp density (root/10cm) | 48~100 | 48~100 | 48~100 | 48~100 | ||||||
Weft density (root/10cm) | 21~50 | 21~50 | 21~50 | 21~50 | ||||||
Areal density(kg/m2) | 1~2.4 | 1.1~2.5 | 1~2.4 | 1.1~2.5 | ||||||
chemical composition (W/m·K) | 600℃ | — | 0.15 | — | 0.15 | |||||
800℃ | 0.17 | — | 0.17 | — | ||||||
1000℃ | 0.21 | — | 0.21 | — |
