Feature of electric winch:
1) Reasonable structure and design hoist
2) Large amount of rope
3) Wire ropes are arranged in order
4) Top quality with competitive and economic price
5) Double Speed: Low Speed and Normal Speed

6) Easy to operate and easy to move



Detailed parameters of the winch
Tonnage	Model	Velocity m/min	Brake	Motor kw	Pull kn	Weight kg	rope capacity
0.5	JK triaxial	35-38	Electromagnetic	3	5	90	80-120
	JK triaxial	25-28	Electromagnetic	3	5	90	80-120
1.5	JK triaxial	25-28	Electromagnetic	7.5	15	220	100-200
	JK triaxial	35-38	Electromagnetic	7.5	15	220	100-200
	JK four axis	15-18	Electromagnetic	7.5	15	300	100-200
2	JK triaxial	25-28	Electromagnetic	11	20	270	100-200
	JK triaxial	35-38	Electromagnetic	11	20	270	100-200
	JK four axis	15-18	Electromagnetic	11	20	300	100-200
5	JK four axis	22-25	Hydraulic	18.5	50	900	150-300
	JK four axis	12-14	Hydraulic	18.5	50	900	150-300
8	JK speed regulating four axes	6-8	Hydraulic	YZR18.5-6	80	1700	200-400
10	JK speed regulating four axes	6-8	Hydraulic	YZR22-6	100	1900	200-400



1. Slow hoist: the hoist whose rated speed of wire rope on the drum is about 7~12m/min.
2. Fast winch: the rated speed of the winch using steel wire rope on the roller is about 30m/min.
3. Electric winch: a winch driven by an electric motor and driven by a driving device to drive the drum to rotate.
Speed regulating hoist: speed regulating hoist.
5. Hand winch: a winch that rotates the drum by means of a driving device driven by human power.
6. Large tonnage non-standard lifting machinery: mainly used for lifting, pulling, unloading, pushing and towing heavy objects.



1. Use the wooden box made of inspection free plates in line with export requirements, and use plywood with a thickness of 9mm-15mm.

2. The wooden box made of solid wood can meet the requirements of export through fumigation and detoxification.

3. boxes board joint is tight, the box board combination is smooth without dislocation, the cloth nail is reasonable, the reinforcement belt is not less than 2, to meet the requirements of the export.

Package:

Electric parts are packed by high quality plywood crate, to reduce distortion in conveying.

Delivery:
1.If the size of whole crane are suitable for container ship, usually by container.
2.If the size is too big, usually by bulk ship or by container after truncation.
3.Transport ways are based o reducing cost for you and keep the winch performance
