Dual-mode LED Display Player HD-A4L
HD-A4 is the second generation Dual-mode LED display player, supports asynchronous playback, synchronous playback, U-disk socket and video auto-scaling functions, with the maximum load capacity 655,360 pixels. Come with Wi-Fi module, support mobile APP management. Equipped with 8GB memory, support expending memory by U-disk. Support optional 4G module, remote cluster control.
HD-A4 is the second generation Dual-mode LED display player, supports asynchronous playback, synchronous playback, U-disk socket and video auto-scaling functions, with the maximum load capacity 655,360 pixels. Come with Wi-Fi module, support mobile APP management. Equipped with 8GB memory, support expending memory by U-disk. Support optional 4G module, remote cluster control.
Features:
1. The maximum loading capacity is 655,360 pixels.
2. Support expending memory by U-disk.
3. Support HD video decoding, 60Hz frame rate output.
4. No need set IP address, it could be identified by controller ID automatically.
6. Come with Wi-Fi, Mobile APP management.
2. Support expending memory by U-disk.
3. Support HD video decoding, 60Hz frame rate output.
4. No need set IP address, it could be identified by controller ID automatically.
6. Come with Wi-Fi, Mobile APP management.
2. Control Mode：
1) Internet unified management: The play box can be connected to the Internet through 3G/4G (optional), network cable connection, or Wi-Fi Bridge.
1) Internet unified management: The play box can be connected to the Internet through 3G/4G (optional), network cable connection, or Wi-Fi Bridge.
2) Asynchronous one-to-one control: Update programs by network cable connections, Wi-Fi connections or USB flash drives. LAN (cluster) control can access the LAN network through by network cable connection or Wi-Fi Bridge.
3). Real-time picture synchronization display: The play box is connected to the sync source through the HDMI high-definition video line, and the sync picture is automatically scaled without any setting.
Parameters
Function | Parameters |
Control Range | Resolution: 655,360 million pixels (1280*512), Widest 16384 pixel, highest 2048 pixel |
Gray Scale | 256-65536 (adjustable) |
Basic Functions | Video, Pictures, Gif, Text, Office, Clocks, Timing, etc. Remote, Temperature, Humidity, Brightness, PM Value, etc. Support Synchronized picture auto-zooming, Playing Live Screen Without Video Processor |
Video Format | HD video hard decoding, 60Hz frame rate output. AVI, WMV, RMVB, MP4, 3GP, ASF, MPG, FLV, F4V, MKV, MOV, DAT, VOB, TRP, TS, WEBM, etc. |
Image Format | Support BMP, GIF, JPG, JPEG, PNG, PBM, PGM, PPM, XPM, XBM, etc. |
Text | Text editing, Image, Word, Txt, Rtf, Html, etc. |
Document | DOC, DOCX, XLSX, XLS, PPT, PPTX, etc. Office2007 Document format |
Time | Classic Analog Clock, digital clock and various of clock with image background |
Audio output | Double track stereo audio output |
Memory | 8GB Flash Memory, Expanding memory by U-disk |
Communication | 100M/1000M RJ45 Ethernet, Wi-Fi, 3G/4G, LAN, USB |
Working Temp | -40℃-80℃ |
Port | IN：12V Power Adapter*1, 1Gbps RJ45*1, USB 2.0*1, Test Button*1, GPS, 3G/4G(Optional), Sensor port*1, HDMI*1 OUT：1Gbps RJ45*1，AUDIO*1 |
Power | 18W (12V DC power supply) |
Product Description
1.Flight Case
2.Wooden Case
Shenzhen Wanzhou Optoelectronics Co., Ltd. is an excellent supplier of LED display solutions. We are specialized in the R&D, production and marketing of LED display screens. As an independent industry park, Wanzhou covers an area of more than 2, 000 square meters, with registered capital of 10 million Yuan and nearly 200 employees. We are equipped with full series automatic production lines, including advanced manufacturing equipments and perfect testing devices, which guarantee the monthly production capacity of 5,000 square meters of LED displays. These also make us one of the top three manufacturers equipped with full automatic production lines in South China.
Our R&D team takes up 14% of the total staff. Most of our R&D engineers have more than 10 years' experience in LED industry. They are the base support to our new product development and custom service. We have continuously developed several profiled screens and achieved made success in developing traffic wireless solution display screens. In order to design and develop higher quality products, our R&D team always try the best to meet Euro-standards for electronic products, as well as to meet the special requirements from customers. Our products have been passed German EMC Certification and Euro EN12966 Certification, as well as ISO9001:2000, CCC, CE, FCC and RoHS certifications.
With perfect designed products, integrated solutions including both hardware and software, and superior product and service guarantee, Wanzhou has been highly praised by domestic and overseas customers. We have been shipping qualified products and services to more than 100 countries and regions all over the world, such as the USA, Japan, Russia, Sweden, Turkey, Poland, France, Israel, Argentina, Spain, etc.
We value the power of cooperative teamwork. We take "Quality & Honesty" as our belief, and "Being the Best Global Supplier of LED Display Solutions" as our goal. We are always producing high quality LED display screens, and building a world famous brand - Wanzhou.
Our R&D team takes up 14% of the total staff. Most of our R&D engineers have more than 10 years' experience in LED industry. They are the base support to our new product development and custom service. We have continuously developed several profiled screens and achieved made success in developing traffic wireless solution display screens. In order to design and develop higher quality products, our R&D team always try the best to meet Euro-standards for electronic products, as well as to meet the special requirements from customers. Our products have been passed German EMC Certification and Euro EN12966 Certification, as well as ISO9001:2000, CCC, CE, FCC and RoHS certifications.
With perfect designed products, integrated solutions including both hardware and software, and superior product and service guarantee, Wanzhou has been highly praised by domestic and overseas customers. We have been shipping qualified products and services to more than 100 countries and regions all over the world, such as the USA, Japan, Russia, Sweden, Turkey, Poland, France, Israel, Argentina, Spain, etc.
We value the power of cooperative teamwork. We take "Quality & Honesty" as our belief, and "Being the Best Global Supplier of LED Display Solutions" as our goal. We are always producing high quality LED display screens, and building a world famous brand - Wanzhou.
FAQ
Q1: Are you a factory or trading company?
A1. We are a factory established in 2008.
Q2: How can I place an order? A2: Please
provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
Q3: How can I pay?
A3: We support a variety of payment methods, the most common is the T/T.
A3: We support a variety of payment methods, the most common is the T/T.
Q4: Where is it used for? A4: Indoor,outdoor, rental use.
Widely used for advertising, policy advocacy， stage background event, rental business, live show, concert, etc.
Widely used for advertising, policy advocacy， stage background event, rental business, live show, concert, etc.
Q5: How long is
the warranty period? A5: 2-3 years.
the warranty period? A5: 2-3 years.
Q6: How to Contact You?
