Новый дизайн ТВ-приемник и аксессуары 5-1000 МГц Catv РЧ-разрядник защита от перенапряжения
- Категории: Other Radio & TV Accessories >>>
- Поставщик: Good,Mind,Electronics,(Shenzhen),Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Description
Specification
Place of Origin:Guangdong,China | ||||||
Model Number:GDISO-003-2(5493) | ||||||
ITEM | TYPICAL | Q.C LIMIT | TEST CONDITIONS | |||
Freq range | 5 ~ 1000 MHz | |||||
Insertion loss | -0.8dB | -1.0dB max. | 5 ~ 1000 MHz | |||
Return loss | 22dB | 20dB min. | 5-1000 MHz | |||
RF shielding | 85dB | 85 dB min. | 5 ~ 1000 MHz | |||
Galvanic isolation (EN50083-1) | ||||||
between center conductor and shield on both ports | 230VAC Rms 50/60Hz not exceeding 2.0mA Rms | |||||
between cable Input shield and Subscriber shield | 2120VDC for at least one minute not exceeding0.7mA leakage current | |||||
Surge Withstand Capability | ||||||
CABLE IN PORT | CAT B3, 6KV, 3KA | Input port-IEEE C62.41-1991 Category B-3 Combo wave,6kV,3kA | ||||
Subscriber PORT | CAT A3, 6KV, 200A | output port-IEEE C62.41-1991 Category A-3 ring wave,6kV,200A | ||||
Connector | F-FEMALE | All port | ||||
Impedance | 75 ohm | All port | ||||
Size | 35W*96L*22H | |||||
