FPR1010-NGFW-K9 Specification | ||
NGFW | 650 Mbps | |
Next-Generation Intrusion Prevention System (NGIPS) | 650 Mbps | |
Dimensions (H x W x D) | 1.82 x 7.85 x 8.07 in. | |
Form factor (rack units) | DT | |
Integrated I/O | 8 x RJ-45 | |
Integrated network management ports | 1 x 10M/100M/1GBASE-T Ethernet port (RJ-45) | |
Serial port | 1 x RJ-45 console | |
USB | 1 x USB 3.0 Type-A (500mA) | |
Storage | 1 x 200 GB | |
Power supply configuration | +12V and -53.5V | |
AC input voltage | 100 to 240V AC | |
AC maximum input current | < 2A at 100V, < 1A at 240V | |
AC maximum output power | 115W (55W of +12V and 60W of -53.5V) | |
AC frequency | 50 to 60 Hz | |
AC efficiency | >88% at 50% load | |
Redundancy | None | |
Fans | None | |
Noise | 0 dBA | |
Rack mountable | Yes. Separate kit must be ordered. | |
Weight | 3 lb (1.36 kg) | |
Temperature: operating | 32 to 104°F (0 to 40°C) | |
Temperature: nonoperating | -13 to 158°F (-25 to 70°C) | |
Humidity: operating | 90% noncondensing | |
Humidity: nonoperating | 10 to 90% noncondensing | |
Altitude: operating | 9843 ft (max) 3000 m (max) | |
Altitude: nonoperating | 15,000 ft (max) |
Model | NGFW | Next-Generation Intrusion Prevention System (NGIPS) | Interfaces |
FPR1010-NGFW-K9 | 650 Mbps | 650 Mbps | 8 x RJ45 |
FPR1120-NGFW-K9 | 1.5 Gbps | 1.5 Gbps | 8 x RJ45, 4 x SFP |
FPR1140-NGFW-K9 | 2.2 Gbps | 2.2 Gbps | 8 x RJ45, 4 x SFP |
