2 4G 5 0 ГГц MU-MIMO OFDMA wi-fi mesh router гигабитный высокоскоростной Wi-Fi ячеистой сети wifi6
- Категории: Routers >>>
- Поставщик: Shenzhen,Junuo,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Specification
Product model | X1 |
Weight | 300g |
Mounting method | Desktop |
Dimensions (excluding accessories) | 99mm x 99mm x 89mm |
Ethernet port | 10/100/1000 Mbps Base-TX port x 3 |
Local power supply | Support 12V 1A DC |
Antenna type | Two high-performance internal array antennas |
Antenna gain | 2.4G：4dBi 5G：4dBi |
Operating frequency bands | 802.11ax/ac/n/a : 5.725GHz-5.850GHz ; 5.15~5.35GHz (China only) 802.11ax/b/g/n : 2.4GHz-2.483GHz (China only) |
Wi-Fi data rate | 2.4G:2*2 11ax 573Mbps 5G:2*2 11ax 1200Mbps |
Wi-Fi power | 2.4G：20dBm@MCS7/BW20(EVM-30dB) 5G: 17dBm@MCS9/BW80(EVM-32dB) |
Maximum total transmitting power | 2.4 GHz: 23 dBm (combined power) 5 GHz : 20 dBm (combined power) The actual transmission power is subject to relevant regulations. |
Modulation technology | OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps MIMO-OFDM (11n): MCS 0-31 MIMO-OFDM (11ac): MCS 0-9 MIMO-OFDM (11ax): MCS 0-11 |
Modulation mode | 11b: DSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps 11a/g: OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM 11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM |
Power adjustment | Automatic |
Reset | Supported |
Status LED | Solid on / Breathing / Network error (The LED can be turned off using software.) |
Operating temperature / Storage temperature | -10ºC～40ºC/-40ºC～70ºC |
Operating humidity / Storage humidity | 5%～95% (non-condensing) |
Protection class | IP41 |
Maximum total power | <15W |
EMC | GB9254、EN301 489、EN55022、FCC Part 15、RSS-210 |
Certification | FCC/CE/CCC/RoHS |
MTBF | >250000H |
