Electrical ABC Accessories Fiber Optic Drop Cable Clamp Insulation Suspension Dead End Anchor Bonding Clamps
Anchoring clamps for round (ADSS) cables
The anchoring clamps are designed for a fast,easy and reliable
A pair of wedges grips the cable automatically within the conical body.The installation doesnot require any specific tools and the operating time is drastically reduced.
Suspension clamps for round(ADSS) cables
A pair of wedges grips the cable automatically within the conical body.The installation doesnot require any specific tools and the operating time is drastically reduced.
Suspension clamps for round(ADSS) cables
Hook clamps are designed to provide a tangent support for 5 to 20 mm aerial ADSS cables at intermediate poles on cable routes with angle < 20° on access networks (spans up to 70 m).
The suspension clamp for ADSS cable consists of a galvanized steel J hook, a neoprene sleeve and a tightening screw.The clamp may be installed on poles using either a pig tail bolt or 2 pole bands.
Dead End Clamp
The suspension clamp for ADSS cable consists of a galvanized steel J hook, a neoprene sleeve and a tightening screw.The clamp may be installed on poles using either a pig tail bolt or 2 pole bands.
Dead End Clamp
Dead End Clamp is designed for a fast, easy and reliable deadending of ber optic cables on access networks with spans up to 100m.
A pair of wedges grips the cable automatically within the conical body.
No special tools are required.
No special tools are required.
Item No. | Cross section(mm²) | Conductor(mm) | Breaking load(KN) | |||
AC - O - 05 AC - O - 06 AC - O - 07 AC - O - 08 AC - O - 10 | 16 - 25 16 - 25 16 - 35 16 - 25 16 - 25 | 3 - 7 3 - 6 3 - 7 6 - 8 8 - 10 | 3 3 5 4 5 | |||
NF010 NF012 NF014 NF016 | 35 - 50 50 - 70 70 - 95 95 - 120 | 10 - 12 12 - 14 14 - 16 16 - 18 | 8 8 8 8 | |||
ACC | - | 2 - 6 | 1 | |||
Suspension Clamp | ||||||
Material | Material | Conductor(mm) | Breaking load(KN) | |||
PT - 1 PT - 2 PT - 3 | Rubber, Steel Rubber, Steel Rubber, Steel | 8 - 12 10 - 15 15 - 20 | 4 4 4 | |||
ARC | - | 3 - 9 copper cable | - | |||
CSC | 4 - 9 copper cable | |||||
