Hantek Hdg3012b 5 в 1 произвольный генератор сигналов функция/гармонический

Model

HDG3102B

HDG3082B

HDG3062B

HDG3042B

HDG3022B

HDG3012B

Channel

2

Wavelength

2M

Frequency range

100MHz

80MHz

60MHz

40MHz

25MHz

15MHz

Sampling rate

300MSa/s

Voltage resolution

16Bits

Waveform

Standard waveform output

sine wave, square wave, triangular wave, pulse wave, noise, harmonics

Arbitrary waveform output

160 kinds of arbitrary waveforms, including exponential rise, exponential fall, ECG signal, Gauss, half vector, Lorentz, dual tone
μlti-frequency, DC voltage, etc

Frequency property

Sine wave

1 μHz ~ 100 MHZ

1 μHz ~ 80 MHZ

1 μHz ~ 60 MHZ

1 μHz ~ 40 MHZ

1 μHz ~ 25 MHZ

1 μHz ~ 15 MHZ

Square wave

1 μHz ~ 15MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

Pulse wave

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

Triangle wave

1 μHz ~ 2 MHZ

1 μHz ~ 2 MHZ

1 μHz ~ 2 MHZ

1 μHz ~ 2 MHZ

1 μHz ~ 2 MHZ

1 μHz ~ 2 MHZ

Harmonic

1 μHz ~ 50 MHZ

1 μHz ~ 40 MHZ

1 μHz ~ 30 MHZ

1 μHz ~ 20 MHZ

1 μHz ~ 10 MHZ

1 μHz ~ 5 MHZ

Noise (3 db)

100 MHZ bandwidth

Arbitrary wave

1 μHz ~ 20 MHZ

1 μHz ~ 20 MHZ

1 μHz ~ 20 MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

1 μHz ~ 15 MHZ

Resolution

1μHz

Precision

±1ppm, 18~28℃

Triangular wave property

Linear

≤ 1% of peak output (typical, 1kHz, 1Vpp, symmetry 100%)

Symmetry

0% ~ 100%

Arbitrary wave property

Wavelength

2M

Vertical resolution

16 Bits

Sampling rate

1μSa/s~62.5 MSa /s, 1μSa/s resolution

Time of rise/fall

Ns of 9 or higher

Overshoot

Typical (1Vpp)

≤5%

Harmonic property

Harmonic frequency

≤16

Harmonic type

Even harmonics, odd harmonics, all harmonics

Harmonic amplitude

All harmonic amplitude can be set.

Harmonic phase

All harmonic amplitude can be set.

Amplitude property (50Ω terminal)
