Водяной насос мембранный высокого давления 18 9
Водяной насос мембранный высокого давления 18 9
Водяной насос мембранный высокого давления 18 9
Водяной насос мембранный высокого давления 18 9
Водяной насос мембранный высокого давления 18 9
Водяной насос мембранный высокого давления 18 9

Водяной насос мембранный высокого давления 18 9


Поделиться:

Цена:3 776,43 ₽ - 4 963,30 ₽*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики







RV water treatment
Yacht and boat water treatment
Agriculture irrigation


Housing water supply boost
High level building water boost
Liquid transfer






For better user experiences




1.Flow rate up to 5.0 GPM [18.9 LPM]
3.Automatically turn on and off
5.Quiet operation
7.On-demand use
2.Can run dry without damage
4.Self priming & built-in check valve
6.Chemically resistant materials
8.Designed for spraying and fluid transfer


Product Name
Newmao 51 series water pump DC 12V/24V
Pump Type
5 Chambers Positive Displacement Diaphragm Pump
Max Flow Rate
5.0 GPM [18.9 LPM]
Max Pressure
70 PSI / 4.8 Bar Max shut-off pressure
Voltage
DC 12V / 24V
Max Amp
9.0 A
Fuse
18.0 A
Switch Type
Built-in bypass and on-demand pressure switch
Diaphragm Material
Santoprene
Valve Material
Viton, and EPDM is available
Duty Cycle
Continuous
Self Priming
6' [1.8 m] suction
Max Fluid Temp
140 °F [60 °C]
Inlet & Outlet Port
3/4"QUICK ATTACH


The 51 Series is our general-duty on-demand positive displacement pump. It provides reliable performance in high water flow, moderate pressure applications. This 5 chamber diaphragm pump provides up to 5.0 gallons per minute and is capable of self-priming, up to 6 vertical feet, and can run dry without damage. Serves 3 or more 3/4" outlets. This automatic demand water system. pump has a built-in pressure switch, which automatically starts and stops when the faucet is opened and closed. They're easy to install, service and winterize..


Model
Voltage
Open flow
(GPM/LPM)
Max draw
Shut-off pressure
(PSI / BAR)
Ports
Wire connections
NMDP51-G30-60-12
12V
3.0 / 11.5
10A
60 / 4.2
3/4"QUICK ATTACH
2-pin / Lead
NMDP51-G30-60-24
24V
3.0 / 11.5
5.5A
60 / 4.2
3/4"QUICK ATTACH
2-pin / Lead
NMDP51-G40-60-12
12V
4.0 / 15.0
13A
60 / 4.2
3/4"QUICK ATTACH
2-pin / Lead
NMDP51-G40-60-24
24V
4.0 / 15.0
7.0A
60 / 4.2
3/4"QUICK ATTACH
2-pin / Lead
NMDP51-G50-60-12
12V
5.0 / 18.9
17A
60 / 4.2
3/4"QUICK ATTACH
2-pin / Lead
NMDP51-G50-60-24
24V
5.0 / 18.9
9.0A
60 / 4.2
3/4"QUICK ATTACH
2-pin / Lead
NMDP51-G50-70-12
12V
5.0 / 18.9
18A
70 / 4.8
3/4"QUICK ATTACH
2-pin / Lead
NMDP51-G50-70-24
24V
5.0 / 18.9
10A
70 / 4.8
3/4"QUICK ATTACH
2-pin / Lead






Performance




Unit N.W
2.76 KG
Unit Size
(L x W x H)
28.4 cm x 15.9 cm x 14 cm
Unit G.W
3.22 KG
Master Carton Qty
8 pcs / carton
Master Carton Size (L x W x H)
57.5 cmx 32.5 cmx 29.5 cm
Master Carton Weight
25 KG
