Портативный КПК idata 95 Вт 1D 2D портативный сборщик данных сенсорный экран Android терминальное устройство с Wi-Fi

Quad-core 1.3GHz

Operating System:

Android 6.0

Memory (ROM+RAM):

95W/95UHF: 16GB + GB
95V/95S: 8GB + 1GB

EXpansion Slot:

Micro SD card

Display:

95W/95S/95UHF: 3.5 inch HD display (960*640)
95V: 3.5 inch HVGA (480*320)

Touch Panel:

Industrial-grade capacitive touch panel

Camera (Optional):

95W/95S/95UHF: 8 MP, aotofocus lens, LED flash
95V: 8 MP/5MP, autofocus lens, LED flash
Exit Window: Corning®Gorilla® glass

Keypad:

Durable industrial keypad with interior transmission light

Battery:

95W/95S/95V: 3.7V 4000mAh rechargeable lithium polymer battery (6000mAh battery optional)
95UHF: 3.7V 6000mAh rechargeable lithium polymer battery

Audio:

Built-in microphone

Notification:

Vibrator alerts/LED/Audio notification

Vibration Motor:

Built-in programmable vibration motor
Sensor: G-sensor

Structural Parameters
Dimensions (LxWxD):

95W/95S/95V: 152mm * 68mm * 24mm

Weight:

95W/95S/95V: 255g (standard battery included)
95UHF: 383g (standard battery included)

Communication Transmission
Wireless WAN (Network frequency):

2G: B2/B3/B5/B8
3G: WCDMA: B1 CDMA&EVDO: BC0 TD-SCDMA: B34/B39
4G: FDD-LTE: B1/B3/B5 TDD-LTE: B38/B39/B40/B41

Wireless WAN (Data service):

GSM/GPRS/EDGE/CDMA/UMTS/HSPA/HSPA+EVDO/WCDMA/TD-SCDMA.TDD-LTE/FDD-LTE

Wireless LAN:

WiFi 802.11 a/b/g/n

BT:

BT 4.0+LE
GPS: GPS/AGPS/BEIDOU/GLONASS

Operating Environment
Development Tools:

Android SDK + JDK + Eclipse

Programming Language:

Java, C

Operating Temp.:

-20°C ~ 60°C (-4°F ~ 140°F)

Storage Temp.:

-40°C ~ 60°C (-40°F ~ 140°F) battery included
-40°C ~ 70°C (-40°F ~ 158°F) battery not inlcuded

Relative Humidity:

0~95% (on-condensing)

Drop Specification:

95W/95S/95V: 1.5 meter drops to concrete ground

Tumble Specification:

95W/95S/95V: 500 0.5m tumbles (1000 hits)

Sealing: IP65

Electrostatic Discharge:

Conforms to ± 15 kV air discharge, ± 8kV direct discharge

1D Laser Scanner
Optical Resolution: ≥4mil
Scan Depth of Field: 3.81 cm ~ 60.98cm
Scan Angle: 47°±3° (Standard)
Scan Speed: 102±12 scans/sec

RFID (95V/95W)
Frequency: 13.56 MHz
Reading Distance: Within 50mm
Protocol: ISO14443A/14443B/15693
NFC: Optional

RFID (95UHF)
Protocol: ISO18000-6C (EPC C1G2)
Frequency: 902-928MHz
Antenna: Cicularly polarized 2dB / Linearly polarized 1.4 dBi
Max Output Power: 1W(＜30 dBm)
Data Capture Range: Within 2.5m (3m for special tags)
Nominal Write Range: Within 0.8m

Input/Output Ports
USB port: 1(Micro USB port)
Charger Port: 1 (Charging interface at the bottom)
OTG: 95W/95S/95UHF support

Accessories
Standard: 95V/95W/95S: Battery, Power Adapter, Wrist Strap, Hand Strap
95UHF: Extended Battery, Power Adapter, Wrist Strap, Hand Strap
Optional: 95V/95W/95S: Bottom Charging Cable, USB Cable, Charging Cradle, 4-slot Battery Cradle, Screen Protector, Carry Case,
Waist Bag, Extended Battery
95UHF: Bottom charging cable, USB cable, Screen protector
