Product Description

Summary of Stock Preparation Inflow Pressure Screen

NLS inflow pressure screen (foil set outside the screen basket) is a comparatively advanced screening equipment around the world in modern time, featuring high screening quality, bigger capacity and lower pulp pulse, applied to fine screening of wood pulp, straw pulp and waste paper pulp, especially as a screening equipment used before the web of paper machine.

Stock Preparation Inflow Pressure Screen Advantage

1. Smaller motor power, lower energy consumption but bigger capacity.
2. Centripetal structure, low pulsation, good evenness on web.
3. Diffusing outlet design, smooth accept flow, companion flange without spacer, inner surface polishing treatment, seamless connection of pipeline, no fiber hanging.

4. Modular design for main motor and drive, stable and reliable structure, easy and fast installation and maintenance.

5. Equipped with auto oiling device and mechanical sealing water monitoring and alarming device, detection sensor port reserved to transfer bearing temperature rise and vibration, high automatic level.

Stock Preparation Inflow Pressure Screen main specification

Model	Nominal Area (㎡)	InletConsistency (%)	Capacity-Hole (T/D)	Capacity-Slot (T/D)	Inlet Pressure (MPa)	Motor Power (KW)
NLS20	0.46	0.15-1.0	20-40	15-25	0.1-0.4 0.1-0.6	15
NLS21	0.75			30-60		25-45	18.5
NLS225	1.00			60-100		50-75	22
NLS22	1.32			70-130		55-80	22
NLS23	1.90			110-160		80-120	30
NLS24	2.54			140-260		100-160	37
NLS255	2.77			200-300		120-250	45
NLS25	3.36			250-400		150-300	45
NLS26	4.37			260-520		180-320	55
NLS27	5.37			350-600		220-400	75
NLS28	6.40			420-700		260-480	90
NLS29	7.66			500-900		350-600	110
