Высокое качество Гибридный архитектуры хранения Многоуровневое хранение данных 5288
- Категории: Servers >>>
- Поставщик: Beijing,Haitian,Hutong,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Specification
Form Factor | 4U rack server |
Processors | 1 or 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series), up to 205 W 1 or 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series), up to 205 W |
Chipset | Intel C622 |
Memory | 24 DDR4 DIMM slots, 2933 MT/s; up to 12 Intel® Optane™ PMem modules (100 series), 2666 MT/s |
Internal Storage | Supports hot-swappable hard drives with the following configuration options: Front: • 24 x 3.5-inch SAS/SATA hard drives Embedded: • 4 x 3.5-inch SAS/SATA hard drives Rear: • 16 x 3.5-inch SAS/SATA hard drives • 16 x 3.5-inch SAS/SATA hard drives + 4 x 2.5-inch SAS/SATA hard drives or NVMe SSDs • 14 x 3.5-inch SAS/SATA hard drives (configurable with 4 NVMe SSDs) + 4 x 2.5-inch SAS/SATA/NVMe SSDs (This configuration does not support internal hard disk and I/O module 1) Flash storage: • Two M.2 SSDs |
RAID | RAID 0, 1, 1E, 5, 50, 6, or 60; optional supercapacitor for cache power-off protection; RAID-level migration, drive roaming, self- diagnosis, and web-based remote configuration |
Network Ports | LAN on motherboard (LOM): 2 x 10GE + 2 x GE ports Flexible NIC: 2 x GE, 4 x GE, 2 x 10GE, 2 x 25GE, or 1/2 x 56G FDR IB ports |
PCIe Expansion | Up to 10 PCIe 3.0 slots, including 1 for a RAID controller card and 1 for a flexible NIC |
Fan Modules | 4 hot-swappable counter-rotating fan modules with optional N+1 redundancy |
Power Supply | 2 hot-swappable PSUs with optional 1+1 redundancy. Supported options include: • 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC) • 1500 W AC Platinum PSUs 1000 W (input: 100 V to 127 V AC) 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC) |
Management | • iBMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening. • iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/ VNC KVM; supports CD-free deployment and the Agentless feature, simplifying management. • (Optional) Configured with the FusionDirector management software to provide advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automatic entire-lifecycle management. |
Operating Systems | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Citrix XenServer, VMware ESXi For details, see https://www.xfusion.com/en/ |
Security | Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, and security front panel |
Operating Temperature | 5°C to 40°C (41°F to 104°F) (ASHRAE Class A3 compliant) |
Certification | CE, UL, FCC, CCC, and RoHS |
Installation Suite | L-shaped guide rails, adjustable guide rails, and holding rails |
Dimensions (H x W x D) | 175 mm x 447 mm x 748 mm (6.89 in. x 17.60 in. x 29.45 in.) |
Company Profile
Company Profile
Founded in 2019 with a registered capital of 10 million yuan, Beijing Haitian Interconnection Technology Co., Ltd. is mainly committed to the marketing of computer and electronic products, application software services and system integration for industrial users, and will provide overall solutions and services for industrial users as the core development strategic goal of the company. The company's main agent products are: servers, disk arrays and system software; The company's main business is divided into four modules, namely product sales, system integration, business consulting and enterprise IT services.
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Why Choose Us
Unique customer service system: The company reasonably combines product sales and after-sales service, and promises customers "five heart service": "buy at ease", "use at ease", "service patience", "work with concentration" and "after-sales enthusiasm" for customer needs, which has won unanimous praise from customers.
Certifications
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1. How could I get a sample?
2.Whether you could make our brand on your products?
Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
3. Whether you could make your products by our color?
Yes, The color of products can be customized if you can meet our MOQ.
4. How to guarantee the quality of your products?
1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order.
2.Whether you could make our brand on your products?
Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
3. Whether you could make your products by our color?
Yes, The color of products can be customized if you can meet our MOQ.
4. How to guarantee the quality of your products?
1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
