Бесперебойный источник питания SKE с эффективным режимом частоты-В переменного
- Категории: >>>
- Поставщик: Shenzhen,Smartkey,Power,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Description
* True double-conversion
* Microprocessor control optimizes reliabilit
* Input power factor correction
* Output power factor 0.8
* Wide input voltage (110 V – 300 V)
* Converter mode available
* ECO mode for energy saving
* Generator compatible
* Charger capacity expansion to 6A for long-run models
* Smart SNMP works well with either USB or RS-232 together
* Comprehensive display allows easy monitoring and access of UPS status
* Microprocessor control optimizes reliabilit
* Input power factor correction
* Output power factor 0.8
* Wide input voltage (110 V – 300 V)
* Converter mode available
* ECO mode for energy saving
* Generator compatible
* Charger capacity expansion to 6A for long-run models
* Smart SNMP works well with either USB or RS-232 together
* Comprehensive display allows easy monitoring and access of UPS status
MODEL | GH11- 6K(L) | GH11- 10K(L) | ||||
PHASE | 1 phase in / 1 phase out | |||||
CAPACITY | 6000 VA / 4800 W | 10000 VA / 8000 W | ||||
INPUT | ||||||
Nominal Voltage | 208/220/230/240VAC | |||||
Low Line Loss | 110 VAC ± 3% at 50% Load 176 VAC ± 3% at 100% Load | |||||
Low Line Comeback | 120 VAC ± 3% at 50% Load 186 VAC ± 3% at 100% Load | |||||
High Line Loss | 300 VAC ± 3% | |||||
High Line Comeback | 290 VAC ± 3% | |||||
Frequency Range | 46 Hz ~ 54 Hz or 56 Hz ~ 64 Hz | |||||
Power Factor | ≥ 0.99 @ 100% load | |||||
OUTPUT | ||||||
Nominal Voltage | 208/220/230/240VAC | |||||
AC Voltage Regulation | ± 1% | |||||
Frequency Range (Synchronized Range) | 46 Hz ~ 54 Hz or 56 Hz ~ 64 Hz | |||||
Frequency Range (Batt. Mode) | 50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz | |||||
Current Crest Ratio | 3:1 (max.) | |||||
Harmonic Distortion | ≤ 3 % THD (Linear Load)；≤ 6 % THD (Non-linear Load) | |||||
Bypass to Inverter | Zero | |||||
Inverter to Bypass | Zero | |||||
Waveform (Batt. Mode) | Pure Sinewave | |||||
EFFICIENCY | ||||||
Line Mode | 0.89 | 0.9 | ||||
Battery Mode | 0.88 | 0.89 | ||||
BATTERY | ||||||
Standard Model | Battery Type | 12 V / 7 AH | 12 V / 9 AH | |||
Numbers | 16 | 16 | ||||
Typical Recharge Time | 9 hours recover to 90% capacity | |||||
Charging Current | Default:1.0 A ± 10%, Max.:2.0A ± 10% | Default:1.0 A ± 10%, Max.:2.0A ± 10% | ||||
Float Charging Voltage | 218.4 VDC ± 1% | |||||
Battery Type | Depending on applications | |||||
Numbers | 16-20pcs(adjustable) | |||||
Charging Current | Default:4.0 A ± 10%, Max.:6.0A ± 10% | Default:4.0 A ± 10%, Max.:6.0A ± 10% | ||||
Float Charging Voltage | 273 VDC ± 1% (based on 20 pcs batteries) | |||||
INDICATORS | ||||||
LCD Panel | UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions | |||||
ALARM | ||||||
Battery Mode | Sounding every 4 seconds | |||||
Overload | Sounding twice every second | |||||
Fault | Continuously sounding | |||||
PHYSICAL | ||||||
Standard Model | Dimension | 369 x 190 x 688 | 442 x 190 x 688 | |||
Net Weight (kgs) | 61 | 75 | ||||
Long-run Model | Dimension | 369 x 190 x 318 | 442 x 190 x 318 | |||
Net Weight (kgs) | 12 | 18 | ||||
ENVIRONMENT | ||||||
Operation Humidity | 0-95 % RH @ 0- 40°C (non-condensing) | |||||
Noise Level | Less than 55dBA @ 1 Meter | Less than 58dBA @ 1 Meter | ||||
MANAGEMENT | ||||||
Smart RS-232/USB | Supports Windows® 2000/2003/XP/Vista/2008,Windows® 7/8, Linux, Unix, and MAC | |||||
Optional SNMP | Power management from SNMP manager and web browser | |||||
Company Profile
FAQ
Q1: Why you should choose us?
---16 years UPS experiences
---Professional team for both oversea and domestic market
--UPS provider of SCO meeting 2015 and Shanghai-Kunming high-speed railway project
---Qualified product plus competitable prices
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---We provide 12-24 months warranty since the delivery date and free maintenance /
replacement during warranty period.
Q3: What kind of certification you have?
---ISO9000, CE,ROHS,and so on
Our products could pass different labor testing according to different countries’ requirements.
Q4: Delivery time:
---Standard products could be delivered within 15 days; customized products could be
developed within 10-30days.
---16 years UPS experiences
---Professional team for both oversea and domestic market
--UPS provider of SCO meeting 2015 and Shanghai-Kunming high-speed railway project
---Qualified product plus competitable prices
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---We provide 12-24 months warranty since the delivery date and free maintenance /
replacement during warranty period.
Q3: What kind of certification you have?
---ISO9000, CE,ROHS,and so on
Our products could pass different labor testing according to different countries’ requirements.
Q4: Delivery time:
---Standard products could be delivered within 15 days; customized products could be
developed within 10-30days.
Note:Actual freight is subject to order, Please contact us before payment.
