10 лет гарантии 1 кВт 2 3 Вертикальная ветровая турбина ветрогенератор морской корабль или для
- Категории: Renewable Energy >>>
- Поставщик: Yichun,Enten,Science,And,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
1,Curved blade design,utilizes wind resource effectively and obtains a higher power generation.
2,Coreless generator, Horizontal rotation and aircraft wing design reduce the noise to an unperceivable level in natural
environment.
3,Wind resistance. Horizontal rotation and triangular double fulcrum design make it only bear a small wind pressure even in strong wind.
4,Rotation radius. smaller rotation radius than other types of wind turbines, space is saved while efficiency improved.
5,Effective wind speed range. special control principle expended the wind speed to 2.5 ~ 25m/s, utilizes wind resource effectively and obtains a higher power generation.
2,Coreless generator, Horizontal rotation and aircraft wing design reduce the noise to an unperceivable level in natural
environment.
3,Wind resistance. Horizontal rotation and triangular double fulcrum design make it only bear a small wind pressure even in strong wind.
4,Rotation radius. smaller rotation radius than other types of wind turbines, space is saved while efficiency improved.
5,Effective wind speed range. special control principle expended the wind speed to 2.5 ~ 25m/s, utilizes wind resource effectively and obtains a higher power generation.
Specification
Started wind speed (m/s) | 1.3 m/s | 1.3 m/s | 2 m/s | 2 m/s | 2 m/s | ||||
Cut-in wind speed (m/s) | 2.5 m/s | 2.5 m/s | 3 m/s | 3 m/s | 3 m/s | ||||
Rated Wind speed (m/s) | 10 m/s | 10 m/s | 10 m/s | 10 m/s | 10 m/s | ||||
Rated voltage(AC) | 12/24V | 12/24V | 12/24V/48v | 24V-120v | 24V-220v | ||||
Rated power(W) | 300W | 600W | 800W | 1000W | 2000W | ||||
Max power(W) | 350W | 650W | 850W | 1100W | 2100W | ||||
Rotor Diameter of Blades(m) | 0.6m | 0.6m | 1.1m | 1.1m | 1.1m | ||||
Product assembly weight (Kg) | <20Kg | <22Kg | <37Kg | <70Kg | <37Kg | ||||
Blades height(m) | 0.8m | 1m | 1.32m | 1.64m | 1.92m | ||||
Safe wind speed (m/s) | 45m/s | ||||||||
Blades quantity | 3 | ||||||||
Blade material | fiber glass | ||||||||
Generator | coreless generator 3 phase AC | ||||||||
Generator protection grade | IP54 | ||||||||
Work environment temperature | -25℃-45℃ | ||||||||
