Product Description


GT3-8 Steel Coil Wire Straightener and Cutter Servo Motor Cutter Type
GT Series High Speed Steel Wire Straightening and Cutting Machine used for straighening and cutting 2-5/3-6/3-8mm hot-rolled and cold rolled steel coil wire and deformed rebar. mostly used in steel mesh produce plant, precast concrete component produce facotry, normal building project, construction, tunnel, bridge, dam, high-speed road, High-speed train and so on.

GT3-8 Steel Coil Wire Straightener and Cutter Servo Motor Cutter Type
Main Technical Specification:
Steel Wire Straightener & Cutter
- Working Capacity: 3-8mm
- Working Speed: 120-130m/min
- Max. Working speed: 150m/min
- Servo Motor Cutting Mode
- 6m Rebar Collect Stacker
- Voltage:3Phase, 380V, 50Hz
- Power: 15+4.0KW
- Servo Motor:4.0KW




Working Vidoes




Technical Specification




Model
GT3 - 8
Applicable Industries
Building Material Shops, Manufacturing Plant, Retail, Construction works , Energy & Mining
Working Capacity
3-8mm, Cold Rolled & Hot Rolled Round Bar/Deformed Rebar
Finish Product Length
0.25 - 6m, Adjustable OR customized
Length Tolerance
≤±1 mm
Straightness
≤2mm/m
Working Speed
100-130 m/min, Max. 150m/min
Straightening Mode
Rotating Straightening Drum
Wire Feeding Mode
Electric Motor
Wire Cutting Mode
Servo Motor Cutting
Total Motor Power
15+4.0KW
Main Straightening Motor
15Kw, normal motor
Servo Motor
4.0 KW
Control Mode
PLC (Siemens)
Steel Wire Strength(Steel Grade)
Tensile Strength ≤ 550MPa Low Carbon Steel Wire
Electric capacity
≥20KVA
Power Supply Line
Cross-sectional Area: 6mm2 ; Material: Copper Material
Air consumption
Working Pressure 0.6MPa, Flow Rate 18m3/h(0.3m³/min)
Voltage
3 Phase, 380V 50Hz or Customized
Dimension(L*W*H)
1600mm×1200mm×1300mm
Weight (KG)
1.8 tons
Warranty
1 Year
Key Selling Points
Long Service Life
Mian Advantage
High Efficient and High Working Speed


Technical Advantages


1. Suitable for straightening and cutting cold-rolled round bar/ribbed bar, hot-rolled round/ribbed bar.
2. Intelligent control: The machine is controlled by PLC ,touch screen and servo motor (Housine servo),Frequency converter control working speed. Easy operation and working reliable
3. Low failure rate: Due to the fine processing of parts and strict quality control, after installation and debugging, under normal working conditions, it can maintain trouble-free operation for a long time.
4. World Advanced & Leading technology: Machine straightening and cutting technology
5. There are four working speeds: 70m/min, 100m/min, 130m/min and 150m/min, Normally working speed: 130m/min, if you finish product length less than 2m, suggest 70-100m/min. Max. Working speed: 150m/min
6. High cutting accuracy: length tolerance: ≤ ±1mm
7. High straightness: ≤ 2 mm/m
