Performance
Passenger Capacity
4 Seats
Max.Speed
35-42km/h(adjustable)
Driving Range
80km
Climbing Ability
<20%
Braking Distance
<3.5
Mini Turning Radius
3.5m
Min.Clearance
105mm
Recharge Time
5-7hours
Dimension
L*W*H
2645*1206*1890mm
F/R Tread
855/980mm
Axle Distance
1670mm
Curb Weight
520kgs
Box Loading Capacity
Around 300kg
Box Size
1100*650*300
Standard Configurations
Motor
ADC Brand 3.8KW Motor (USA brand)
Controller
Curtis Controller (48V 275A) (USA brand)
Battery
Huge capacity deep cycle lead-acid battery 8V/piece 6 pieces
Body & Roof
Injection molding design separable replacement
Windshield
Tempered glass with wiper
Seats
Sponge&artificial Leather with flexible two-point seat belts + three-point belt
Rear View Mirror
2 pcs
Tire
Golf tyre 18×8.50-8 Wheel diameter 452mm
Chassis
High strength structural steel
Steering
Gear Steering, auto Backlash Compensation
Brake System
Rear Brake+ Composite Pedal Brake
Front Axle
Non Independent Suspension, Leaf Spring + Cylindrical Hydraulic Shock Absorb
Rear Axle
Integral Rear Axle,Non Independent Suspension, Spring, Sylinder Type Hydraulic Shock Absorb
