Product Information
Feature:
1. 384x288 / 640x512 Pixels.2. OLED (1440X1080), A High-performance display.
3. 1000m accurate laser distance measurement.
4. Equipped with electronic compass and motion sensors.
5. Compact and lightweight, easy to carry around.
6. Multiple cross-hatching and customisable memory calibration parameters can be set.
7. With the latest lison II detail enhancement algorithm for a clearer picture.
8. WIFI transmission of images and built-in video and photo functions.
9. Protection class IP66, weatherproof.
1. 384x288 / 640x512 Pixels.2. OLED (1440X1080), A High-performance display.
3. 1000m accurate laser distance measurement.
4. Equipped with electronic compass and motion sensors.
5. Compact and lightweight, easy to carry around.
6. Multiple cross-hatching and customisable memory calibration parameters can be set.
7. With the latest lison II detail enhancement algorithm for a clearer picture.
8. WIFI transmission of images and built-in video and photo functions.
9. Protection class IP66, weatherproof.
Items | Technical Parameter | ||||||||
RS519-384 | RS535-384 | RS535-640 | RS550-640 | ||||||
Detector | Type | Vox | |||||||
Pixel | 384x288 | 640x512 | |||||||
Pixel Spacing | 12 um | ||||||||
Wavelength range | 8-14 um | ||||||||
NETD | ≤35mk | ||||||||
IR Lens | Focus | 19mm/F1.0 | 35mm/F1.0 | 35mm/F1.0 | 50mm/F1.0 | ||||
FOV | 13.8°x10.4° | 7.5°x5.7° | 12.5°x10.0° | 8.8°x7.0° | |||||
Focusing Method | Manual | ||||||||
Monitor | OLED, 0.39'', 1440x1080 | ||||||||
Image Display | Eyepiece Parameter | 40 mm | |||||||
Magnification | 1.77x-7.08x | 3.26x-13.04x | 1.91x-7.64x | 2.72x-10.88x | |||||
Diopter Adjustment | -5D~+5D | ||||||||
Laser Rangefinder | Can be extended (optional), ranging from 10 to 1000m | ||||||||
Electronic compass/motion sensor | Support | ||||||||
WI-FI | Support | ||||||||
Image Performance | Frame Rate | 50 Hz | |||||||
Image Correction | Auto/Manual | ||||||||
E-ZOOM | 2x, 4x | ||||||||
Hot Spot Tracking | Support | ||||||||
Cross Reticle | Support | ||||||||
Palette | White heat, black heat, iron red, red heat, forests | ||||||||
Image Transmission | WIFI real-time image transmission, photography, and video | ||||||||
Image Storage | Memory | 32 GB | |||||||
Photos | Support | ||||||||
Video | Support | ||||||||
Power System | Battery Type | Single standard 26500 rechargeable lithium battery, replaceable. | |||||||
Battery Working Time | ＞5h | ||||||||
Charging Method | Support online charging | ||||||||
External Power Supply | DC5V/2A | ||||||||
Interface | Data interface | Type-C | |||||||
Installation interface | Three standard fixing screw holes, and different optional mounting brackets. | ||||||||
Physical characteristic | Diamension (mm) | ≤165*80*65mm/≤165*110*65mm （With laser） | ≤190*80*65mm/≤190*110*65mm （With laser） | ≤190*80*65mm/≤190*110*65mm（With laser） | ≤200*80*65mm/≤200*110*65mm （With laser） | ||||
Weight (g) | ≤470g/ ≤532g（With laser） | ≤520g/ ≤582g（With laser） | ≤525g/ ≤587g（With laser） | ≤570g/ ≤632（With laser） | |||||
Environment Parameter | Working temperature | -30℃~+55℃ （-22°F~131°F） | |||||||
Storage temperature | -40℃~+70℃ | ||||||||
Max. Recoil Power | 800g/ms | ||||||||
Capsulation | IP66 | ||||||||
Detection distance | Human (1.08x0.5) m | 750m | 1400m | 1400m | 1900m | ||||
Car (2.3x2.3) m | 1800m | 2200m | 2200m | 3200m | |||||
Recognition distance | Human（1.8×0.5）m | 367m | 700m | 700m | 1000m | ||||
Car（2.3×2.3）m | 910m | 1100m | 1100m | 1600m | |||||
