Электрические стальные столбы XINTONG электрические
- Категории: Telecommunication Towers & Accessories >>>
- Поставщик: Yangzhou,Xintong,Transport,Equipment,Group,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Description
Height | From 10M-100M or according to client's requirement | ||||||
Suit for | Electric Power Transmission and Distribution | ||||||
Shape | Polygonal or Conical | ||||||
Material | Normally Q235B/A36,Yeild Strength>235MPa | ||||||
Q345B/A572.Yeild Strength>345MPa | |||||||
As well as Hot Rolled coil from ASTM572. GR65,GR50.SS400 | |||||||
Power Capacity | 10kV to 500kV | ||||||
Tolerance of the dimension | According to client's requirement | ||||||
Joint of Poles | Slip joint, flanged connected | ||||||
Surface treatment | Hot-dip-galvanized followingASTM123, or any other standard by client's requirement | ||||||
Standard | SO9001:2008 | ||||||
Length of per section | Within 13M once forming | ||||||
Welding Standard | AWS(American Welding Society)D 1.1 | ||||||
Production Process | Raw materialtest-cutting-bending-welding-dimension verify-flange welding-hole drilling sampleassemble-surfaceclean-galvanization or power coating /painting-recalibration-packages | ||||||
Packages | Packing with plastic paper or according to client's requirement | ||||||
Life Period | More than 25 years. it is according to installing environment | ||||||
