Product name | Evaporator Molecular | ||||||||
Model | ASK-F/006 | ASK-F/010 | ASK-F/015 | ASK-F/025 | ASK-F/035 | ||||
Barrel Diameter(mm) | 60 | 80 | 100 | 150 | 200 | ||||
Evaporation Area(m2) | 0.06 | 0.1 | 0.15 | 0.25 | 0.35 | ||||
Feeding rate(L/H) | 0.1~2 | 0.1~4 | 0.2~6 | 0.5~10 | 0.5~15 | ||||
Feeding flask volume(L) | 0.5 | 1.0 | 1.5 | 2 | 5 | ||||
Distillate receiving flask(L) | 1 | 1 | 2 | 5 | 5 | ||||
Residue receiving flask(L) | 1 | 1 | 2 | 5 | 10 | ||||
Motor power(W) | 90 | 120 | 120 | 120 | 200 | ||||
Vaccum Level(mbar) | 0.001 | ||||||||
Rotation speed(rpm) | 50~500rpm | ||||||||
Operation Temperature(c) | Up to 300℃ | ||||||||
Electrical requirement | 220V/50-60Hz(other options can be provided) | ||||||||
