1 кВА 3 онлайн ИБП экологическая батарея резервный стабилизатор напряжения система источник бесперебойного
- Категории: Uninterruptible Power Supplies (UPS) >>>
- Поставщик: FOSHAN,KOMISTAR,ELECTRONIC,CO.,LTD
Поделиться:
Описание и отзывы
Характеристики
Features:
1. Ultra-Small, ultra-thin personalized design, with a variety of personalized color optional.
2. Output short-circuit protection.
3. Long back up design, able to last 24 hours.
4. Battery low & high voltage protection.
5. Adopt CPU design, computer interface, have self detection function.
6. With three-level lightning protection, multi protection of your equipment.
7. No load automatic shutdown (selection).
8. Multi-function alarm.
2. Output short-circuit protection.
3. Long back up design, able to last 24 hours.
4. Battery low & high voltage protection.
5. Adopt CPU design, computer interface, have self detection function.
6. With three-level lightning protection, multi protection of your equipment.
7. No load automatic shutdown (selection).
8. Multi-function alarm.
Line Interative Pure Sine Wave UPS | ||||||||||
Model | CYE1K（S） | CYE2K（S） | CYE3K（S） | CYF6K（S） | CYF10K（S） | |||||
Phase | Single-phase | |||||||||
Capacity | 1000VA/800W | 2000VA/1600W | 3000VA/2400W | 6000VA/4800W | 10000VA/8000W | |||||
Input | ||||||||||
AC Mains Input Voltage | 145-280VAC | |||||||||
Input Frequency Range | 46Hz - 54Hz or 56Hz - 64Hz | |||||||||
Power Factor | 100% load ≥ 0.98 | |||||||||
Output | ||||||||||
Output Voltage | 220 ± 10% | |||||||||
Voltage Range (DC Mode) | ±2% (±10% AC Mode) | |||||||||
Frequency Range (Sync Calibration Range) | 47Hz- 53Hz or 57Hz- 63Hz | 46Hz- 54Hz or 56Hz - 64Hz | ||||||||
Frequency Range (DC Mode) | 50 Hz ± 0.25 Hz | 50 Hz ± 0.1 Hz or 60 Hz± 0.1 Hz | ||||||||
Surge Ratio | 3: 1 | |||||||||
Harmonic Distortion | ≤3% THD(linear load) | |||||||||
Transfer Time | ≤8ms | |||||||||
Waveform | Pure sine wave | |||||||||
Battery | ||||||||||
Standard Model Battery Type | 12V/7.2AH | |||||||||
Standard Model Battery Quantity | 2 | 4 or 6 | 6 | 14 | 16 | |||||
Standard Model Charging Current | 1.5A(Max) | 2.0A(Max) | ||||||||
Standard Model Charging Voltage | 41.0VDC ± 1% | 82.1VDC ± 1% | 82.1VDC ± 1% | 178.5VDC ± 1% | 178.5VDC ± 1% | |||||
Long Run Model Battery Type | Depend on requirments | |||||||||
Long Run Model Battery Quantity | 3 | 6 | 8 | 16(18, 20 optional) | ||||||
Long Run Model Charging Current | 6A(Adjustable) | 8A(Adjustable) | 6A(Adjustable) | |||||||
Long Run Model Charging Voltage | 41.0VDC ± 1% | 82.1VDC ± 1% | 109.4VDC ± 1% | 218.4VDC ± 1% | ||||||
Appearance | ||||||||||
LED Or LCD Display | Load level, battery capacity, AC Mode, battey mode, bypass mode, fault indication | |||||||||
Alarm | ||||||||||
Battery Mode | Alarm beeps every four seconds | |||||||||
Low Battery | Alarm beeps every second | |||||||||
Overload | Alarm beeps every second | |||||||||
Fault | Alarm beeps continuously | |||||||||
Environment | ||||||||||
Temperature And Humidity | Humidity 20-90%, temperature 0-40°C (non-condensing) | Humidity 0-95%, temperature 0-40°C (non-condensing) | ||||||||
Noise(dB) | < 40dB at one meter distance | < 45dB at one meter distance | ||||||||
Control Management | ||||||||||
Smart RS-232/USB | Support Windows® 2000/2003/XP/2008,Windows® 7/8,Linux,Unix | |||||||||
Optional SNMP | Power Management supports SNMP management and network management | |||||||||
External Dimension | ||||||||||
Standard model Dimension(mm) | 352*145*213 mm | 450*192*335 mm | 450*192*335 mm | 390*192*720 mm | 390*192*720 mm | |||||
Standard model Weight(KGS) | 12.96 | 29.7 | 33 | 55 | 59 | |||||
Long Run Model Dimension(mm) | 352*145*213 mm | 350*192*335 mm | 350*192*335 mm | 390*192*335 mm | 535*192*348 mm | |||||
Long Run Model Weight(KGS) | 9.54 | 15.97 | 21.55 | 28 | 30 | |||||
FAQ
Q1: Are you a manufacturer or a trading company?
We are a factory more than 20years experience to provide good quality with competitive price.
Q2:How about the delivery time?
Ready sample;7 working days for bulk order after your deposit is confirmed.
Q3: What kind of certification you have?
---ISO9001,ISO14001, CE,ROHS,UL,and so on ---All series UPS pass different labor testing according to different countries’
requirements.
requirements.
Q4: Can I have a sample order?
---Yes, we welcome sample order to test and check quality.
Q5: Do you support OEM?
---Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
