Плетеная латунная сетчатая ткань для фильтрации жидкости

Описание и отзывы

Характеристики

Pure Copper Wire Mesh Screen Fabric



1. Pure Copper Wire Mesh Screen Fabric Overview

Copper mesh series products are available in copper wire mesh, bronze wire mesh, and brass wire mesh. They look similar in appearance and color. Due to the different compositions of metal materials, each product has different characteristics and use effects.

Copper wire mesh is woven with wire threads by plain weave, twill weave or dutch weave. According to different requirements, we can manufacture copper wire cloth with different shapes or densities.
Copper wire screen has good thermal conductivity and non-magnetic, so it can be used for a fireplace screen or Faraday cage. With high density, it can be used for filter or insect screens. With a beautiful appearance, copper wire cloth can decorate ceilings or be used as space partition, exquisite artworks.



The difference between several types of copper mesh:



Item	Red copper wire mesh	Brass wire mesh	Phosphor bronze wire mesh	Tinned copper wire mesh
Material	99% pure copper wire	H65 wire (65%Cu-35%Zn )	Tin bronze wire	Tinned copper wire
Mesh count	2-250 mesh	2-250 mesh	2-350 mesh	2-100 mesh
Weave type	Plain/ twill/ dutch weave
Common size	width 0.5-1.5m; length 30m/roll, Also can be as per your demand
Common feature	Nonmagnetic, good ductility, Wear resistance, Fast heat transfer, Good electrical conductivity
Special features	Sound insulation; Electron filtration	Apply to Newspaper/typing/chinaware printing usual; Smoking screen	Apply to Chinaware printing, screening all kinds of particles, powders, and porcelain clay	High-temperature resistance, anti-aging, and long service life
Common Applications	EMI/RFI shielding; Faraday cage			Engine filter to car, Noise reduction, damping(suspension )









2. Pure Copper Wire Mesh Screen Fabric Technical Details



Mesh	Wire Diameter	Opening (mm)
SWG	mm	inch
6 mesh	22	0.711	0.028	3.522
8 mesh	23	0.610	0.024	2.565
10 mesh	25	0.508	0.020	2.032
12 mesh	26	0.457	0.018	1.660
14 mesh	27	0.417	0.016	1.397
16 mesh	29	0.345	0.014	1.243
18 mesh	30	0.315	0.012	1.096
20 mesh	30	0.315	0.0124	0.955
22 mesh	30	0.315	0.0124	0.840
24 mesh	30	0.315	0.0124	0.743
26 mesh	31	0.295	0.0116	0.682
28 mesh	31	0.295	0.0116	0.612
30 mesh	32	0.274	0.011	0.573
32 mesh	33	0.254	0.010	0.540
34 mesh	34	0.234	0.0092	0.513
36 mesh	34	0.234	0.0092	0.472
38 mesh	35	0.213	0.0084	0.455
40 mesh	36	0.193	0.0076	0.442
42 mesh	36	0.193	0.0076	0.412
44 mesh	37	0.173	0.0068	0.404
46 mesh	37	0.173	0.0068	0.379
48 mesh	37	0.173	0.0068	0.356
50 mesh	37	0.173	0.0068	0.335
60 × 50 mesh	36	0.193	0.0076	-
60 × 50 mesh	37	0.173	0.0068	-
60 mesh	37	0.173	0.0068	0.250
70 mesh	30	0.132	0.0052	0.231
80 mesh	40	0.122	0.0048	0.196
90 mesh	41	0.112	0.0044	0.170
100 mesh	42	0.012	0.004	0.152
120 × 108 mesh	43	0.091	0.0036	-
120 mesh	44	0.081	0.0032	0.131
140 mesh	46	0.061	0.0024	0.120
150 mesh	46	0.061	0.0024	0.108
160 mesh	46	0.061	0.0024	0.098
180 mesh	47	0.051	0.002	0.090
200 mesh	47	0.051	0.002	0.076



3. Pure Copper Wire Mesh Screen Fabric Features:



♥ Beautiful appearance for decoration.
♥ Good ductility.
♥ Good thermal conductivity and non-magnetic.
♥ Lightweight and high density.
♥ Recyclable.

♥ Excellent EMI/RFI/EMC shielding performance.
♥ Beautiful and attractive surface.
♥ Non-magnetic.
♥ Excellent electrical conductivity.









4. Pure Copper Wire Mesh Screen Fabric Applications :

Where can copper woven mesh be used?
♥ RFI/EMI/RF Shielding
♥ Electronic information security
♥ Faraday Cages
♥ Power generation
♥ Insect Screens
♥ Outer space exploration and research
♥ Fireplace Screen
♥ Electronic security
