Introduction of Underground Four Wheel Drive Truck Customizable Mine Lhd Mining Scooptram For Sale
Mining LHD is a kind of soil transportation machinery that uses a bucket to shovel soil and load broken soil into a bucket for transportation. It can complete comprehensive operations such as shoveling, loading, transporting, unloading, layered filling, and local compaction. Suitable for site leveling work in railway, road, water conservancy, electric power, and other projects. Scrapers have the advantages of simple operation, freedom from terrain constraints, independent operation, fast driving speed, and high production efficiency. It is suitable for Class I to Class III soils, such as when cutting more than Class III soils, it is necessary to loosen the soil in advance. The widely used scrapers in the market are divided into two types: internal combustion scrapers and electric scrapers. Internal combustion scrapers are suitable for well-ventilated working environments, with flexible and efficient characteristics; Electric scrapers are more environmentally friendly and pollution-free. Its characteristics, structure, classification, development achievements, operation process, safety regulations, etc. are described in detail.zmwm02
Product Paramenters
Parameters of Underground Four Wheel Drive Truck Customizable Mine Lhd Mining Scooptram For Sale
1. Main configuration of the whole machine | ||||||
(1) Engine | ||||||
model | Volvo TAD853VE | WD12G310E221 | ||||
Rated power | 235kW | 226kW | ||||
Rated speed | 2200r/min | 2200r/min | ||||
manufacturer | Sweden Volvo | Weichai Power | ||||
(2) Hydraulic torque converter | ||||||
model | C5000 | |||||
type | Single-stage three-element, with hydraulic pump drive | |||||
manufacturer | Imported from the United States | |||||
(3) Power transmission (Dana) | ||||||
model | 36000 | |||||
type | 4 forward gears and 4 reverse gears complete power shift | |||||
manufacturer | Imported from the United States | |||||
(4) Drive axle | ||||||
model | 19D | D81 | PR105 | |||
type | Multi-disc wet brake (spring brake, hydraulic release) | |||||
manufacturer | Imported from the United States | Imported from Germany | Huafeng Customization | |||
(5) Parking brake | ||||||
model | ZDQ-250 | |||||
type | Caliper disc brake | |||||
manufacturer | Huafeng Customization | |||||
2. Main technical parameters of the complete machine | ||||||
1 | Car volume (stacking) (m3) | 10.5 | ||||
2 | Rated load capacity (t) | 20 | ||||
3 | Maximum traction force (kN) | ≥200 | ||||
4 | Climbing ability (°) | ≥14（25%） | ||||
5 | Minimum ground clearance (mm) | ≥310 | ||||
6 | Minimum turning radius (mm) | R (outside) | ≤8190 | |||
R (inside) | ≤5110 | |||||
7 | Driving speed (km/h) | Gear I | 5.8±0.5 | |||
Gear II | 9.5±0.5 | |||||
Gear III | 21.0±2.0 | |||||
8 | Overall dimension of the whole vehicle (mm) | long | 9000±100 | |||
Width (excluding rearview mirror) | 2228±50 | |||||
high | 2460±50 | |||||
9 | Wheelbase (mm) | 5058 | ||||
10 | Vehicle weight (t) | 20.1 | ||||
11 | Tire type | 16.00-25 | ||||
12 | Fuel tank volume (L) | 310 | ||||
13 | Volume of hydraulic oil tank (L) | 200 | ||||
Details Images
Photos of Underground Four Wheel Drive Truck Customizable Mine Lhd Mining Scooptram For Sale
FAQ
1.Factory
Q: Are you Underground Service Vehicles manufacturer?
Q: Are you Underground Service Vehicles manufacturer?
A: We are the Mining Lhd manufacturer. Yimei Underground Mining Lhd factory address is:Jining cirty, Shandong province, China.
2. Warranty
Q: How to identify the quality about Underground Diesel Lhd for sale?
A: Our Mining Transport Vehicles have a 12 months warranty after sale.
3. Packing
Q:What is the container size of Underground Diesel Lhd?
A:Generally, 100 sets rides with 200 GP container or more, the actual size can adjust with how many you need.
4. Lead time
Q: How many days it takes before you deliver the goods to us?
A: For these Tunnel Loader Scooptram, we need 1 or 2 more days to order wooden boxes or pallets, and 3 days to book flight/vessel and ship the goods to named port/airport.
