Сетевая камера с распознаванием номерных знаков 1080 P
- Категории: Security >>>
- Поставщик: Shenzhen,Jana,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Features
▶Starlight
▶2MP ( 1920 × 1080 ) @30fps
▶Support smart H.265/H.264 coding ICR auto switch, true day/night
▶Up to 100m IR night view distance; motorized zoom lens 3D
▶DNR, true WDR, HLC, BLC and ROI coding
▶Built-in micro SD card slot, up to 128GB
▶1CH audio input; 1CH audio output
▶1CH alarm input; 1CH alarm output
▶DC12V/PoE power supply
▶Support three streams
▶P2P function optional
▶IP67
▶Support mobile surveillance by smart phones with iOS and Android OS)
▶2MP ( 1920 × 1080 ) @30fps
▶Support smart H.265/H.264 coding ICR auto switch, true day/night
▶Up to 100m IR night view distance; motorized zoom lens 3D
▶DNR, true WDR, HLC, BLC and ROI coding
▶Built-in micro SD card slot, up to 128GB
▶1CH audio input; 1CH audio output
▶1CH alarm input; 1CH alarm output
▶DC12V/PoE power supply
▶Support three streams
▶P2P function optional
▶IP67
▶Support mobile surveillance by smart phones with iOS and Android OS)
▶Intelligent analytic: video abnormality (video tampering,scene change), license plate recognition
License plate detection
▶Three Video Stream Detection method;
▶Use starlight 2MP 1/2.8 "CMOS image sensor
▶Intelligent analytics: video abnormality (video tampering, scene change), license plate recognition
▶Detection Speed Max 70km/H
▶Detection Distance 3-10 m
Video Surveillance
▶Support smart H.265/H.264 coding ICR auto switch, true day/night
▶Up to 100m IR night view distance; motorized zoom lens 3D
▶DNR, true WDR, HLC, BLC and ROI coding.
▶Support mobile surveillance by smart phones with iOS and Android OS
▶Built-in micro SD card slot, up to 256GB
Data Interaction
▶Support result push function to server
▶Support RTSP API Docking for video
▶ Support Http Post Request from program
▶ Support FTP Agreement
▶ Support UPnP Agreement
▶ Support RTMP Agreement
Basic Functions
◎ User Setting and Management
◎ Http Visit Verification
◎ White and Black List
◎ Event Detection and Alarm Settings
◎ Schedule Settings
◎ Display Settings
◎ Vehicle classification settings
◎Week Schedule setting of vehicle classification
Camera Size
279.5 × 100.3 × 88.9 (mm) Net Weight: 1.04 KG
Ports
Multiple interface support, video, network, control, display synchronization and transmission.
Accessories
Different Accessories are used in different scenes to fix the camera in proper places. Mostly could be used in ceiling mounted, wall mounted, pillar fixed, wall corner fixed . Get more details by inquiry admin@szjanatech.com
Specification
Model: J-823A3 | Network 1CH RJ45 | PoE : Yes IEEE802.3af |
Image Size: 1920*1080 | Video Output: NVR | Waterproof: IP67 |
E.Shutter :1 / 25 s ~ 1 / 100000 s | 1CH Audio Input;1CH Audio Output | IR Distance:50-70m |
Lens: 2.8~12mm@F1.4, motorized | Storage : Built-in micro SD card slot; up to 256GB | Snapshot: Overview and cutout of plate for picture |
Lens Mount Φ14 | Reset : Available | White list : 10000 |
Video Compression Smart H.265 / H.265+ / H.265 / Smart H.264 / H.264+ / H.264 / MJPEG | Alarm: 1 CH Alarm in 1CH Alarm out | Capture Speed Range 0-70km/h |
Resolution 1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240 | 1CH RS485 | Power Supply:DC12V/PoE |
Bit Rate :64 Kbps ~ 6 Mbps | 1 CH Wigend | Power Consumption< 11W |
Image Settings ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen NR,etc. adjustable through client software or web browser | Network Protocol: UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS | Operating Environment - 30 °C ~ 60 °C (-22°F~140°F) Humidity: less than 95 % (non-condensing) |
Each ROI to be configured separately | Interface Protocol ONVIF | Installation :Ceiling mounting; Wall mounting |
CONTACT HERE
Email : admin@szjanatech.com; amy@szjanatech.com
Installation Instructions
Access Control for Entrance
1. Speed lower than 40km/h, with deceleration area would be better.
2. Capturing distance 2.5-3 meters.
3. The width of the license plat accounts for 6%-50% of whole image size.
4. Installation Angel of depression ≥15°.
Road Surveillance
1.Speed ranges from 30-70km/h, recognition distance would be 15-30m.
2. Maximum lanes are two.
3. Height of camera would be 4-6 meters, required lens up to 50mm.
4. Installation Angel of depression ≥15°.
Packing & Delivery
Inner Accessories
1.Quick Start Guide
2. Position Paper
3. Screw Kit
4. Backup Cables and Accessories
Inner box
1. Package Size : 29×10×10 (cm)
2. Gross Weight/box: 1.5KGS
Package Carton
1. 10 Sets/Carton
2. Carton Size: 68×36×30(cm)
3.Gross Weight/Carton: 15KGS
Company Profile
Founded in 2015, JANA is a fast-growing parking solution provider committed to offering the value-added services and middle cost value Parking surveillance solutions for construction industrial. Based on LPR video surveillance, JANA expands its value proposition into security industries, featuring Internet of Things communication, and artificial intelligence technologies as its core. Through a worldwide network of distributors and system integrator in over 85 countries and regions, JANA disseminates its products and services in comprehensive solutions with a hope to connect a parking security and growing digital economic.
Company Strength
Professionalism
Years of in-depth security industry experience shape us as a professional at service of security solutions
Innovation
Up-to-the-minute technologies and strong R&D power keep in step with the fast-growing market.
Integrity
Honest and trustworthy towards all partners and customers nourish JANA’s reputation.
Reliability
Dependable and qualified security equipment meets the precise security need.
Win-win
Healthy distribution channel ensures sustainable and win-win partnership.
Interoperability
Simplified compatibility offers more choices for efficient performance.
Years of in-depth security industry experience shape us as a professional at service of security solutions
Innovation
Up-to-the-minute technologies and strong R&D power keep in step with the fast-growing market.
Integrity
Honest and trustworthy towards all partners and customers nourish JANA’s reputation.
Reliability
Dependable and qualified security equipment meets the precise security need.
Win-win
Healthy distribution channel ensures sustainable and win-win partnership.
Interoperability
Simplified compatibility offers more choices for efficient performance.
International
Distinguish from other enterprise, JANA cares more international service to offer the best.
FAQ
1. Can this camera working as cctv?
Yes, its three stream as cctv camera
2. Can I interface it with my own software?
The webcam support a interface debugging with any server by http post or server to cloud
3. How to be the distributor?
We have a discount price to be distributors.
Yes, its three stream as cctv camera
2. Can I interface it with my own software?
The webcam support a interface debugging with any server by http post or server to cloud
3. How to be the distributor?
We have a discount price to be distributors.
4. Do you have local agent?
We had some distributors over there
