GCr15
Product application
IGCr15 is the most commonly used high chromium bearing steel with high hardenability and can achieve high and uniform hardness
after heat treatment. Used for bearing sleeves, steel balls, and rollers of grades H to C, it can be used for bearing large loads,
other mechanical parts that require high wear resistance, high elastic limit, and high contact fatigue strength, as well as various precision measuring tools.
after heat treatment. Used for bearing sleeves, steel balls, and rollers of grades H to C, it can be used for bearing large loads,
other mechanical parts that require high wear resistance, high elastic limit, and high contact fatigue strength, as well as various precision measuring tools.
PRODUCT PARAMETER
Chemical composition | ||||||||||||||
C | Si | Mn | S | P | Cr | Ni | Mo | |||||||
0.95-1.05% | 0.15-0.35% | 0.25-0.45% | ≤0.025% | ≤0.025% | 1.4-1.65% | ≤0.30% | ≤0.10% | |||||||
Hardness | ||
Full hardness | 42~60 HRC | |
Quenching hardness | 56 HRC | |
Heat treatment and standard
Hot working specification: start temperature 1000-1050 ℃, end temperature 850 ℃.Quenching and tempering specifications: Quenching temperature 730-760 ℃, water cooling, water oil dual liquid cooling or alkali bath cooling, quenching hardness 56HRC. Tempering temperature 160-180 ℃.
APPLICATION EXAMPLES
Used for parts with sliding parts that require high hardness and wear resistance, such as guide pins, bushings, thimbles, exit pins, reset pins, and other mold guide parts.
Suitable for making cold working mold parts, simple molds or stamping mold punches with low service life requirements.
STEEL GRADE & EXECUTIVE STANDARD | ||||
Steel grade | Executive standards | |||
China | T7(A) | GB | ||
Japan | SK7 | JIS | ||
Germany | C70W2 | DIN, DINEN | ||
United Kingdom | 060A67 | BS, BSEN | ||
Delivery status
Delivery status: The steel is delivered in an annealed state. By mutual agreement, delivery can also be made without annealing.
Product classification & specifications | ||||||||||
length | width | thickness | surface process | edge process | ||||||
SK7 heat treatment steel | ||||||||||
SK7 heat treatment steel strip | ||||||||||
SK7 heat treatment steel plate | ||||||||||
SK7 heat treatment steel sheet | ||||||||||
Above all products can be customized according to customer requirements. | ||||||||||
PRODUCT PICKING
Picking way
Usually 250 kg/roll, 8 rolls/pallet.A 20 feet container can loading 10 pallets. Packaging way can be changed according to customer customized requirements
