2-дюймовые Светодиодные Габаритные габаритные огни полуфары

Описание и отзывы

Характеристики

2 inch LED marker clearance light semi truck marker lights



1,  Features



• Available in versions of (3) SMD LEDs and (9) SMD LEDs

• Features engineered lens optics, functions as clearance light, side marker or identification light

• PC lens and housing ultrasonically welded together to ensure a permanent and weater proof seal.

• Right angle 2-pin plug assembly, PVC grommet mounting

• LED circuit board coated with conformal coating for excellent moisture and environmental protection

• Super long life span up to 100,000 hours

• Meets DOT FMVSS 108/SAE requirements

• Rated for 12V, tested to 13.8V

• Also available in multi-voltage 10~30V operating range, or 24V (special order only – minimum may apply)



2,  Part# and Technical Information



Part No.	Description	Input Voltage	Lighting Color	Nos. of LEDs	LED Type	Current Draw (mA) at 13.8V
102003R	Grommet Kit	12 V	Red	3	SMD	60 mA
102003A	Grommet Kit	12 V	Amber	3	SMD	60 mA
102003RM	Kit, Multi-voltage	12~24 V	Red	3	SMD	60 mA
102003AM	Kit, Multi-voltage	12~24 V	Amber	3	SMD	60 mA
102009R	Grommet Kit	12 V	Red	9	SMD	60 mA
102009A	Grommet Kit	12 V	Amber	9	SMD	60 mA
102009RM	Kit, Multi-voltage	12~24 V	Red	9	SMD	60 mA
102009AM	Kit, Multi-voltage	12~24 V	Amber	9	SMD	60 mA
102000G	Grommet only for 2” Round M/C Light
922502P	2-pin Plug for 2” & 2-1/2” M/C Light































































 3,Dimension:

Product Display:
