Product Description
Wall Mounted Electric furnace MS-6 | ||
Specification
Product Technical Parameters | ||||||||||||||||||
Name | Unit | Dual-Purpose Wall Mounted Electric Boiler | ||||||||||||||||
Rated Power | KW | 6 | 8 | 10 | 12 | 16 | 20 | 24 | 32 | |||||||||
Rated Current | A | 9.3 | 12 | 15.2 | 18.3 | 24.3 | 30.3 | 110 | 48.5 | |||||||||
Switch | A | ≧40 | ≧40 | ≧63 | ≧63 | ≧80 | ≧120 | ≧160 | ≧200 | |||||||||
Electricity Meter | A | ≧40 | ≧40 | ≧63 | ≧63 | ≧80 | ≧120 | ≧160 | ≧200 | |||||||||
Rated Voltage/HZ | V/HZ | 380/50 | ||||||||||||||||
Heat Power | Kal | 5426 | 6880 | 8600 | 10320 | 13760 | 17200 | 20640 | 27520 | |||||||||
Thermal Efficiency | 98% | |||||||||||||||||
Thermal Water Yild | Kg/Min | 3.5 | 5 | 6 | 7 | 9 | 10 | 12 | 16 | |||||||||
Using Pressure | Mpa | 0.1-0.3 | ||||||||||||||||
Heating Outlets | G 3/4" | |||||||||||||||||
Heating Inlets | G 3/4" | |||||||||||||||||
Hot Water Output | G 1/2" | |||||||||||||||||
Cold Water Input | G 1/2" | |||||||||||||||||
Set Temperature | ℃ | 30-85 | ||||||||||||||||
Protection Grade | IPx4D | |||||||||||||||||
Power Consumption | °/H | 6 | 8 | 10 | 12 | 16 | 20 | 24 | 32 | |||||||||
Heating Area | ㎡ | 40-60 | 60-80 | 80-100 | 100-120 | 140-160 | 160-180 | 180-220 | 260-300 | |||||||||
Product Size | mm | 700*410*252 | ||||||||||||||||
MS-6 Functions
1. Segmented timeing function
As needed to control the heating and set multiple time-periods.
2. Temperature adjustable function
As needed to control the heating and set multiple time-periods.
2. Temperature adjustable function
The water temperature is 20 ℃ to 85 ℃ can adjust, set the temperature difference (5 ℃ ~ 20 ℃) in order to meet the different needs of different customers.
3. Intelligent constant temperature
Halt machine to heat preservation after the water temperature reaches the setting , the temperature drops at the lowest of its setting, customised heating again, always maintain constant temperature state.
4. Water pump running temperature setting
Electric boiler is equipped with the special power switch of circulating pump, according to the set temperature control of
circulating pump turned on and off.
5. High temperature protection function
High temperature probe, autostop heating if the water temperature is over 95℃ degrees .
6. Low temperature anti freezing protection
Heating starts when water temperature is detected to be below 3℃, autostopping heating when the water temperature rises to 8℃ .
7. Multiple protection function
With multiple protection functions against water shortage, short circuit, power leakage, phase failure and overcurrent, for safer
functioning.
8. Fault prompt functions
In the event of a fault in the electric boiler, the display will automatically indicate the type of fault..
3. Intelligent constant temperature
Halt machine to heat preservation after the water temperature reaches the setting , the temperature drops at the lowest of its setting, customised heating again, always maintain constant temperature state.
4. Water pump running temperature setting
Electric boiler is equipped with the special power switch of circulating pump, according to the set temperature control of
circulating pump turned on and off.
5. High temperature protection function
High temperature probe, autostop heating if the water temperature is over 95℃ degrees .
6. Low temperature anti freezing protection
Heating starts when water temperature is detected to be below 3℃, autostopping heating when the water temperature rises to 8℃ .
7. Multiple protection function
With multiple protection functions against water shortage, short circuit, power leakage, phase failure and overcurrent, for safer
functioning.
8. Fault prompt functions
In the event of a fault in the electric boiler, the display will automatically indicate the type of fault..
Packing & Delivery
Company Profile
Dezhou Maisheng Heating and Cooling Technology Co.Ltd, started in 2005, is a high-tech enterprise focusing on the
research and development, design, production, sales and service of gas wall-hung boilers. The company has strong technical force,
advanced production testing equipment and excellent service team, and has processed and produced thermal energy and refrigeration equipment for many well-known domestic brands, which has received unanimous praise.
Founded its own brand in 2017, Dezhou Maisheng Heating and Cooling Technology Co.Ltd. The company always takes quality and safety as its mission, combines technological innovation, energy conservation and environmental protection, and meticulously creates every product that satisfies users. It has become the largest household wall-hung boiler in northern China As a manufacturing enterprise, Maisheng guarantees that the main components adopt international first-line brands, and the product quality has been certified by international standards such as ISO and CE. We have a production site of more than 40,000 square meters and have 4 fully automated industrial production lines imported from the world. Production capacity reaches 600,000 units.
research and development, design, production, sales and service of gas wall-hung boilers. The company has strong technical force,
advanced production testing equipment and excellent service team, and has processed and produced thermal energy and refrigeration equipment for many well-known domestic brands, which has received unanimous praise.
Founded its own brand in 2017, Dezhou Maisheng Heating and Cooling Technology Co.Ltd. The company always takes quality and safety as its mission, combines technological innovation, energy conservation and environmental protection, and meticulously creates every product that satisfies users. It has become the largest household wall-hung boiler in northern China As a manufacturing enterprise, Maisheng guarantees that the main components adopt international first-line brands, and the product quality has been certified by international standards such as ISO and CE. We have a production site of more than 40,000 square meters and have 4 fully automated industrial production lines imported from the world. Production capacity reaches 600,000 units.
Certifications
FAQ
1. who are we?
We are based in Shandong, China, start from 2022,sell to Eastern Europe(20.00%),North America(20.00%),Southeast Asia(18.00%),South Asia(12.00%),Mid East(10.00%),Western Europe(10.00%),Eastern Asia(10.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
suspended platform,gas boiler,suspended scaffolding,condensing boilers,gondola construction
4. why should you buy from us not from other suppliers?
Industry and trade integration.
18 +years of R & D and production experience.
discount price
5. what services can we provide?
Accepted Delivery Terms: null；
Accepted Payment Currency:null;
Accepted Payment Type: null;
Language Spoken:null
We are based in Shandong, China, start from 2022,sell to Eastern Europe(20.00%),North America(20.00%),Southeast Asia(18.00%),South Asia(12.00%),Mid East(10.00%),Western Europe(10.00%),Eastern Asia(10.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
suspended platform,gas boiler,suspended scaffolding,condensing boilers,gondola construction
4. why should you buy from us not from other suppliers?
Industry and trade integration.
18 +years of R & D and production experience.
discount price
5. what services can we provide?
Accepted Delivery Terms: null；
Accepted Payment Currency:null;
Accepted Payment Type: null;
Language Spoken:null
