Product Description
MP1100 Series Single Phase Online UPS 1kVA-30kVA
MP1100 series 1/1 online UPS 1kVA-30kVA is true online double conversion one phase in one phase out low frequency UPS. This series UPS adopts high-speed microprocessor (MCU), programmable logic device (CPLD) program which are controlled by software, the sixth generation low-exhaust and big-power IGBT and static switch as power components. Capacity range from 1kva to 30kva, input and output voltage can be customer designed suit for different country’s utility.
MP1100 series 1/1 online UPS 1kVA-30kVA suit for home equipment and small factory with liner loads and non liner loads like printer, motors, manufacturing machine, etc, it is widely used in telecom, bank, security, transporting, utility, manufacture, industry, commerce, government, medical equipment etc.
* 35 degree adjustable drawing LCD display panel for 6kVA-10kVA
* UPS operation status, load status, battery status via LCD
* Intelligent digital control, increase the ups stability
* Input power factor correction ( PFC ), reduce pollution to utility grid
* Wide input voltage range, compatible with different utilities
* 8 output power factor lives up to the load trend and stronger load
* Excellent input frequency range, make the ups adapt to the different power supply equipment
* Adopt high precision SMD technology, improve the circuit reliability and running precision
* Cold start
* Intelligent battery management, extend the battery life
* Silencer device, better environment protections
* RS232 communication port, optional USB/SNMP card
* Input line and neutral detecting functions
* Self diagnosis when turn on the UPS, inspect all kinds of ups work status
* Can support software system: windows, windows Net , LAN manager, etc
* Optional standard battery bank or extension battery bank
MP1100 series 1/1 online UPS 1kVA-30kVA suit for home equipment and small factory with liner loads and non liner loads like printer, motors, manufacturing machine, etc, it is widely used in telecom, bank, security, transporting, utility, manufacture, industry, commerce, government, medical equipment etc.
Main Advantages
* High frequency and true online double-conversion* 35 degree adjustable drawing LCD display panel for 6kVA-10kVA
* UPS operation status, load status, battery status via LCD
* Intelligent digital control, increase the ups stability
* Input power factor correction ( PFC ), reduce pollution to utility grid
* Wide input voltage range, compatible with different utilities
* 8 output power factor lives up to the load trend and stronger load
* Excellent input frequency range, make the ups adapt to the different power supply equipment
* Adopt high precision SMD technology, improve the circuit reliability and running precision
* Cold start
* Intelligent battery management, extend the battery life
* Silencer device, better environment protections
* RS232 communication port, optional USB/SNMP card
* Input line and neutral detecting functions
* Self diagnosis when turn on the UPS, inspect all kinds of ups work status
* Can support software system: windows, windows Net , LAN manager, etc
* Optional standard battery bank or extension battery bank
Specification
Model | MP1101kVA | MP1103kVA | MP1104kVA | MP1106kVA | MP1108kVA | MP1110kVA | MP1115kVA | MP1120kVA | MP1130kVA | |||||||||
Nominal capacity (kVA/kW) | 1kVA/0.8kW | 3kVA/2.4kW | 4kVA/3.2kW | 6kVA/4.8kW | 8kVA/6.4kW | 10kVA/8kW | 15kVA/12kW | 20kVA/16kW | 30kVA/24kW | |||||||||
Working mode | Double conversion true online | |||||||||||||||||
Rectifier(Input) | ||||||||||||||||||
Phase | Single phase L+N+G | |||||||||||||||||
Input voltage | 220Vac, 230Vac, 240Vac(customized 110Vac,120Vac, ) | |||||||||||||||||
Range | ±25% | |||||||||||||||||
Input frequency | 50Hz±10%, 60Hz±10%; | |||||||||||||||||
Input THD | <5% | |||||||||||||||||
Soft start | 0～100% 5s | |||||||||||||||||
Charge | ||||||||||||||||||
Charge mode | Constant current to constant voltage, with Auto change | |||||||||||||||||
Float voltage | 54VDC | 216VDC | ||||||||||||||||
Charge current | 5Amp ( option 10Amp) | |||||||||||||||||
Battery | ||||||||||||||||||
Battery type | Maintenance-free lead acid battery | |||||||||||||||||
Battery capacity | 7～999AH settable (according to the capacity) | |||||||||||||||||
Battery number | 4pcs 12V for 48VDC | 16pcs 12V for 192VDC | ||||||||||||||||
Inverter | ||||||||||||||||||
Phase | 1 phase | |||||||||||||||||
Output power factor | 0.8 | |||||||||||||||||
Output voltage | 220Vac; 230Vac; 240Vac ( customized 110Vac,120Vac, ) | |||||||||||||||||
Output voltage distortion | ±1 %( Stable load); ±3%( fluctuant load) | |||||||||||||||||
Freq distortion | 50Hz 60Hz<±0.5%( when out of sync) | |||||||||||||||||
Crest factor | 3:01 | |||||||||||||||||
Output THD | Sine wave ,linear load<3%;non-linear load<5% | |||||||||||||||||
Dynamic characteristic | Instant voltage<±5%(from 0 to100% ), Instant recover time<10ms | |||||||||||||||||
Imbalance load voltage | Output Voltage <±5% | |||||||||||||||||
Overload protection | 115% 10min 125% 1min 150% 1S | |||||||||||||||||
Efficiency | >92%(full load) | |||||||||||||||||
Bypass | ||||||||||||||||||
Phase | Single phase+N | |||||||||||||||||
Voltage | 220Vac; 230Vac; 240Vac (customized 110Vac,120Vac, ) | |||||||||||||||||
Transfer time | <1ms | |||||||||||||||||
Protection parameters | ||||||||||||||||||
Input protection | Input over/low voltage ;over frequency | |||||||||||||||||
Output protection | Over current short circuit ; factor low | |||||||||||||||||
Battery protection | Over charge ; over-discharge | |||||||||||||||||
Temp protection | Environment over temp protection, inverter over temp protection | |||||||||||||||||
Hardware failure | Assistant power abnormal, breaker cut off, breaker overload, power components over current/over voltage etc protection | |||||||||||||||||
Cooling | Compulsive ventilation(with temperature control) | |||||||||||||||||
Environment | Temp: 0～40℃, relative humidity 30%～90 %, ( a 1% decrease against 100 meters’ rise. Altitude 4000m MAX) | |||||||||||||||||
Communication | RS232/ RS485; (optional SNMP card/ dry contact interface) | |||||||||||||||||
Redundancy function | In series or N+1 parallel | |||||||||||||||||
Anti-surge capacity | 10/700μS, 5KA , 8/20μS, 20KA(Optional) | |||||||||||||||||
Safety rate | IP21 | IP31 | ||||||||||||||||
Safety performance | Vin-n Vout-n 3000Vac, creepage<3.5mA isolation resistance >3M(500VDC) | |||||||||||||||||
Noise (dB) | 45～60 | |||||||||||||||||
Mechanical size (W×D×H)mm | 210*520*530 | 220*520*640 | 220*520*760 | 450*600*1200 | ||||||||||||||
Packing size (W×D×H)mm | 286*585*740 | 286*585*840 | 286*585*960 | 520*670*1430 | ||||||||||||||
Net weight(Kg) | 42 | 59 | 59 | 65 | 84 | 92 | 186 | 201 | 251 | |||||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Aerospace Baykee (Guangdong) Technology Co., Ltd. is a backbone enterprise engaged in the research and development of cutting-edge power supply technology under the China Aerospace Science and Technology Corporation and a pathfinder for the application of my country's power supply technology in the field of "advanced, precise and cutting-edge". Aerospace Baykee is established in 2007, a professional manufacturer and exporter with R&D in improving power quality products like uninterrupted power supply (UPS), EPS, solar inverters, modular data center, MPPT solar charge controller, energy storage system, etc. Headquarter in Foshan, the earliest cooperation in China power industry passed and approved by the ISO 9001 & ISO 14001, OHSMS 18001, CE, IEC, 3C, TCL and CQC quality standard. Aerospace Baykee also actively participates in the "One Belt, One Road" initiative by setting up branches and agents in Pakistan, Australia, Philippines, Vietnam, Yemen, and Nigeria to launch company's self-developed products. Currently, Aerospace Baykee is the first-line brand in Pakistan.
Application case
Exhibition
FAQ
Q: Why choose us?
A: We are China Leading UPS &solar system Manufacturer, 14 years experience in producing and marketing
UPS & solar products.
100% QC inspection Before Shipment.
Best Quality & Best Service with Competitive price.
Good after-sale service: 1 years warranty and if possible we provide on-site installation and repairing.
All of our products have the CE certificate, ISO9001,ISO14001,OHSAS18000,TLC, IEC authentication, and Chinese energy conservation certification
Market covers the 100 cities and countries all over the world. Have branch office in Pakistan, Australia, etc.
If you have some problems about MP1100 series online ups , or want to know more details about 3 phase online UPS system, off grid solar inverter system, solar energy storage system, outdoor online UPS, lithium battery, MPPT solar charge controller ,etc. Welcome to contact us!
Looking forward to your inquiry in alibaba.
A: We are China Leading UPS &solar system Manufacturer, 14 years experience in producing and marketing
UPS & solar products.
100% QC inspection Before Shipment.
Best Quality & Best Service with Competitive price.
Good after-sale service: 1 years warranty and if possible we provide on-site installation and repairing.
All of our products have the CE certificate, ISO9001,ISO14001,OHSAS18000,TLC, IEC authentication, and Chinese energy conservation certification
Market covers the 100 cities and countries all over the world. Have branch office in Pakistan, Australia, etc.
If you have some problems about MP1100 series online ups , or want to know more details about 3 phase online UPS system, off grid solar inverter system, solar energy storage system, outdoor online UPS, lithium battery, MPPT solar charge controller ,etc. Welcome to contact us!
Looking forward to your inquiry in alibaba.
