Аппарат для стыковой сварки труб

Цена:*

Стоимость в USD (на сегодня):Узнать

Количество:

SWT-V355H 90-355mm Thermofusion Hdpe Pipe Welding Machine Price Competitive

Hydraulic Butt Fusion MachineSWT- V355H 90MM-355MM (3" IPS -12" / 14'' IPS) Product Details
WELDING RANGE O.D.	90MM - 355MM	PISTON AREA	20.02 cm²
POWER SUPPLY	220V±10%, 50/60HZ	TEMPERATURE RANGE	MAX. 320ºC
HEATER POWER	4.0KW	PACKING DIMENSION	930700670 MM
TRIMMER POWER	1.5KW			650600770 MM
PUMP POWER	0.75KW			650340380 MM
WORKING PRESSURE RANGE	0 - 80 BAR	GROSS WEIGHT	292KGS

The hydraulically operated butt fusion machine is featured by robust, compact and rugged reliability.

The hydraulic power station gives sufficient pressure to butt fusing pipes and fittings with a variety of pressure ratings.

Hydraulic butt fusion machine is compatible with data logger, which records and documents the key parameters of the fusion process.

Product Feature

Product Applications

Product Case
