DLQ 4x2 4cbm DONGFENG гидравлическая система качающийся рычаг мусоровоз/крюк подъемный

General

Chassis brand

Dongfeng

Approx. Dimension

6760*2250*2850 mm

GVW./Kerb Wt.

7300 / 3070 kg

Cab Capacity

2 persons' seat

Air Conditioner

Air Conditioner is optional

Drive Type

4X2, left hand drive

Fuel Type

Diesel

Engine Make & Model

Chaochai

Chassis

Engine Power

95 HP

Emission Standard

Euro III or EURO IV or Euro V

Brake

Air Brake

Wheelbase/No.of axle

3300mm / 2

Tyre Specification

7.50-16

Tyre Number

6 tyres and 1 spare tyre

Max Speed

90 km/h

Paint

Automotive metallic paint

Capacity

4 CBM

Garbage box

Material

Carbon steel

Equipped with

1,Hopper volume: 4CBM, , base plate thickness 5mm, side plate thickness 4mm, made of high quality carbon steel plate,

2,With double hydraulic cylinders, swing operation, cycling time for one swing is 60s, equipped with rear hydraulic support,
hydraulic pilot switch installed outside truck body

Composition

Basic composition: chassis, garbage bucket, hydraulic cylinder, swing arms.

The swing arm container garbage truck can be used in urban area and suburb.

Purpose

The container on the rear of the truck can be put down on the ground to gather garbage at a fixed location. When the container
gathers full, the truck lifts it on the flat bed on the rear of the truck, then dump the garbage in the garbage center.
