30-120 шт. автоматическая упаковочная линия для
- Категории: Home Product Manufacturing Machinery >>>
- Поставщик: Foshan,Sayok,Packaging,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
SN-1L | SN-6L | |
Wet wipes unfolded size | L*H:100-220×100-240mm | (120-210)X(160-220) (length X width) |
Wet wipes folded size | L*H: 80-110×30-90mm | (120-210)X(90-110) (length X width) |
Wipes folding method | Vertically folded N/W type | Vertically folded N/W type |
Bag size | Single bag: L*W: 130-160×50-100mm | Single bag: L*W: 130-160×50-100mm |
batch number | Automatic batch number printing, equipped with ink wheel coding device (low cost, easy to replace) | Automatic batch number printing, equipped with ink wheel coding device (low cost, easy to replace) |
Processing capacity | Single row 40～100 slices/min (single row) | 1200-2400 pieces/minute 15-20 packs/minute (80 pieces/pack) |
Packaging film requirements | 70-130g/㎡ aluminum film packaging paper, Φ≤400mm, width 200-380mm | 70-130g/㎡ aluminum film packaging paper, Φ≤400mm, width 200-380mm |
Inner diameter of raw paper core | Φ 76.2mm (=3") | Φ 76.2mm (=3") |
Total power | 220V 50Hz 3KW | 380V 50HZ 2.15KW |
Drive chain | Main drive chain with tensioner as required | Main drive chain with tensioner as required |
Machine weight | About 1200 kg | 2000kg |
Dimensions | L*W*H: 4000×1200×1800mm | (140-280) LX(90-110)WX(30-80) H |
Instructions for adding liquid to the wet tissue folding machine
1. Spray after the product is cut to control the amount of sprayed liquid, and increase the amount of liquid without squeezing. It is suitable for the production of wet wipes that require a large amount of liquid, such as Jieyin wet wipes, male and female nursing and health care wipes.
Advantages: There is no chemical contamination when folding and cutting, and it will not cause rusting of machine parts;
Disadvantages: After spraying water, it has not been squeezed, and the product is relatively thick.
2. Spraying before the product is cut can control the amount of spraying liquid and squeeze after spraying. Suitable for the production of ordinary cleansing and makeup remover wipes with low liquid content:
Advantages: suitable for direct packaging, suitable for product packaging with certain packaging height requirements;
Disadvantages: Although the folding mechanism is made of stainless steel, some products are corrosive and easy to rust for a long time; the water content cannot be increased (visual inspection: water drops drip when pinching slightly by hand).
Advantages: There is no chemical contamination when folding and cutting, and it will not cause rusting of machine parts;
Disadvantages: After spraying water, it has not been squeezed, and the product is relatively thick.
2. Spraying before the product is cut can control the amount of spraying liquid and squeeze after spraying. Suitable for the production of ordinary cleansing and makeup remover wipes with low liquid content:
Advantages: suitable for direct packaging, suitable for product packaging with certain packaging height requirements;
Disadvantages: Although the folding mechanism is made of stainless steel, some products are corrosive and easy to rust for a long time; the water content cannot be increased (visual inspection: water drops drip when pinching slightly by hand).
Foshan Sayok Packaging Machinery Co.,Ltd., located in Foshan, Guangdong, is dedicated to developing and producing various packaging machinery. With advanced R & D concept, professional technology, mature processing system, rigorous QC management system and considerate after-sales service, we have won a good reputation in the industry. With rich industry knowledge and service experience, we can offer our clients one-stop packaging solutions. We welcome you to visit our factory, and talk about business face to face with us. We firmly believe that our rise in the industry can’t be achieved without your support. We aim to produce more advanced products and co-advance with our clients.
Since we set up the company, we have developed dozens of packaging machines and corollary equipments in several series. From double frequency conversion packaging machine series to advanced three servo packaging machine, and then full-automatic packaging production line. After continuous improving and perfecting, our production techniques have reached industry standard, and thus helped us to win many distributors.
Main products:
We produce pillow type packaging machine, vertical packaging machine, automatic feeding packaging line and corollary equipments, which can be used for packaging of food, vegetable, hardware and daily necessities, etc.
