item | value |
Model Number | 3.8V20F |
Type | Super Capacitor |
Place of Origin | China |
Guangdong | |
Brand Name | YKY |
Supplier Type | Original manufacturer, ODM, Agency, Retailer |
Capacitance | 20F |
Cross Reference | 3.8V40F |
Media Available | datasheet, Photo, EDA/CAD Models |
Tolerance | -20% ~ +80% |
Package Type | Through Hole |
Rated Voltage | 3.8V |
Operating Temperature | -40℃~70℃ |
Specification | SIDE MOUNT |
Voltage - Rated | 3.8V |
ESR (Equivalent Series Resistance) | ≤500mΩ |
Applications | Water meter, Gas meter, Electric meter |
Impedance | ≤500mΩ |
Circuit Type | Isolated |
Temperature Coefficient | -40℃~70℃ |
Current - Leakage | none |
Capacitance Range | 20F |
Application | Power |
Working Temperature | -40 ℃ ~ 85 |
Work Voltage | 2.5~3.8V |
Standard Capacitance(@25±2℃) | 20F |
Tolerance | -20% ~ +80 |
AC (1kHz, 3.8V) Resistance | ≤500mΩ |
Max. discharge current Continuous | 100mA |
Max. discharge current Pulse (1sec | 0.5A |
Max charge voltage/current | 4.2V200MA |
Weight | ≤1.5g |
size: | 08x13 |
