Поделиться:

Цена:932,00 $ - 1 798,00 $*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики





MAIN FEATURES

● High precision feeding: Aiming at the arrival of hi-tech industry, it is controlled by computer closed-circuit feedback system. So that the precision can maintain within +/-0.03mm.
● Phase-style feeding function: It can input 20 sets of different feeding length, each group provides punching for 999 times to satisfy the processing and production of special products (option)
● Manual model: It can input 3 phases manual speed, which can let used operate more easily and feed materials more accuracy.
● High efficiency release device: It can set up release angle quickly, only match cam signal of and adjusted feed thickness can done.
● Feeding length setting: Input feed length on the controller panel directly.
● Feeding unit: The roll adopts middle-hollow style. Being light and with low inertia for electroplate. The surface hardness HRC is 58 and hard chrome plated.








Thin Board Model


MODEL
NC-200
NC-300
NC-400
NC-500
Feed Width
0～200mm
0～300mm
0～400mm
0～500mm
Applicable Material Thickness
0.2～2.5mm
0.2～2.5mm
0.2～2.5mm
0.2～2.5mm
Feed Length
0～9999.99mm
0～9999.99mm
0～9999.99mm
0～9999.99mm
Feeding Speed
20m/min
20m/min
20m/min
20m/min
Way to Relax
Pneumatic relaxation
Pneumatic relaxation
Pneumatic relaxation
Pneumatic relaxation
Product Packaging
Thickened wooden box
Thickened wooden box
Thickened wooden box
Thickened wooden box


Thick Board Model


MODEL
NC-200A
NC-300A
NC-400A
NC-500A
Feed Width
0～200mm
0～300mm
0～400mm
0～500mm
Applicable Material Thickness
0.3～4.5mm
0.3～4.5mm
0.3～4.5mm
0.3～4.5mm
Feed Length
0～9999.99mm
0～9999.99mm
0～9999.99mm
0～9999.99mm
Feeding Speed
20m/min
20m/min
20m/min
20m/min
Way to Relax
Pneumatic relaxation
Pneumatic relaxation
Pneumatic relaxation
Pneumatic relaxation
Product Packaging
Thickened wooden box
Thickened wooden box
Thickened wooden box
Thickened wooden box


Application Scenario








Small Equipment
